Mesh2Splat

Mesh2Splat is a fast surface splatting approach used to convert 3D meshes into 3DGS (3D Gaussian Splatting) models by exploiting the rasterizer's interpolator.
Mesh2Splat comes with a 3DGS Renderer to view the conversion results.

"What if we wanted to represent a synthetic object (3D model) in 3DGS format?"

Currently, the only way to do so is to generate a synthetic dataset (camera poses, image renders and initial sparse point cloud) of the 3D model, and then feed this into the 3DGS pipeline. This process can take several minutes, depending on the specific 3DGS pipeline and model used.

Mesh2Splat instead, by directly using the geometry, materials and texture information from the 3D model, rather than going through the classical 3DGS pipeline, is able to obtain a 3DGS representation of the input 3D models in milliseconds.

Use Cases

Mesh2Splat is built for fast and flexible integration into 3D Gaussian Splatting (3DGS) workflows, especially when traditional pipelines may be too slow or incompatible with certain scenarios. Below are some key use cases:

• 3DGS-only Rendering Pipelines
  Some 3DGS renderers do not support hybrid rendering (i.e., mixing triangle meshes and Gaussians). In these cases, Mesh2Splat enables direct conversion of mesh assets into pure 3DGS format, allowing them to be rendered natively without relying on slower optimization pipelines.

• Fast Initialization for 3DGS Optimization
  When preparing a model for a 3DGS optimization pipeline (e.g., with new sets of images or altered appearance), having a good initial guess is crucial for faster convergence and better results. Mesh2Splat provides a geometry and texture informed initialization that can be used as a strong starting point for further refinement.

• Enhancing Traditional Renderers with Gaussian Primitives
  In pipelines where triangle meshes are the primary representation but 3DGS rendering is supported, Mesh2Splat can be used to convert selected assets into Gaussians. This enables developers and artists to leverage the unique properties of Gaussians.

Features

Converter

• Direct 3D Model Processing: Directly obtain a 3DGS model from a 3D mesh (only .glb format is supported for now).
• Sampling density: you can easily tweak the sampling density (conversion quality) in the settings via a slider.
• Texture map support: For now, Mesh2Splat supports the following texture maps:
  • Diffuse
  • Metallic-Roughness
  • Normal
• Enhanced Performance: Significantly reduce the time needed to transform a 3D mesh into a 3DGS.
• Relightability: Can easily relight the gaussians given a renderer that supports it.

3D model by: M. Pavlovic, “Sci-fi helmet model,” 2024, provided by Quixel. License: CC Attribution Share Alike 3.0. (https://creativecommons.org/licenses/by-sa/3.0/.), you can download it from here

3DGS Renderer

• Visualization options: albedo, normals, depth, geometry, overdraw and pbr properties.
• Gaussian shading: supports PBR based shading.
• Lighting and shadows: simple point light and omnidirectional shadow mapping.
• Shader hot-reload: if you want to experiment with the shaders and 3DGS math, hot-reload is there to make your life easier.
• Mesh-Gaussian occlusion: to improve performance you can use the "Enable mesh-gaussian depth test" to use the mesh as occluder in depth prepass.

Method

The (current) core concept behind Mesh2Splat is rather simple:

• Compute 3D model bounding box

• Initialize a 2D covariance matrix for our 2D Gaussians as:
  ${\Sigma_{2D}} = \begin{bmatrix} \sigma^{2}_x & 0 \\\ 0 & \sigma^{2}_y \end{bmatrix}$

  where: ${\sigma_{x}}\sim {\sigma_{y}}\sim 0.65$
  and ${\rho} = 0$

• Then, for each triangle primitive in the Geometry Shader stage, we do the following:

  • Apply triplanar orthogonal projection onto X,Y or Z face based on normal similarity and normalize in [-1, 1].
  • Compute Jacobian matrix from orthogonal UV space to 3D space for each triangle: $J = V \cdot (UV)^{-1} $.
  • Derive the 3D directions corresponding to texture axes $u$ and $v$, and calculate the magnitudes of the 3D derivative vectors.
  • Multiply the found lengths by the 2D Gaussian´s standard deviation, this way we found the scaling factors along the directions aligned with the surface in 3D space.
  • The packed scale values will be:
    • $packedScale_x = log(length(Ju) * sigma_x)$
    • $packedScale_y = log(length(Jv) * sigma_y)$
    • $packedScale_z = log(1e-7)$

• Now that we have the Scale and Rotation for a 3D Gaussian part of a specific triangle, emit one 3D Gaussian for each vertex of this triangle, setting their respective 3D position to the 3D position of the vertex, and in order to exploit the hardware interpolator, we set gl_Position = vec4(gs_in[i].normalizedUv * 2.0 - 1.0, 0.0, 1.0);. This means that the rasterizer will interpolate these values and generate one 3D Gaussian per fragment in the orthogonal space.

• Perform texture fetches and set this data per gaussian in Fragment Shader.

• Each fragment now atomically appends one gaussian into a shared SSBO.

Performance

Mesh2Splat is able to convert a 3D mesh into a 3DGS on average in <0.5ms.

Build Instructions (Windows)

To build Mesh2Splat, follow the following steps:

Prerequisites

• CMake ≥ 3.21.1
  Required to support Visual Studio 2022 project generation. Older versions may default to unsupported generators.

• Visual Studio 2019 or 2022
  Must include the "Desktop development with C++" workload. Make sure your CMake version is compatible with your Visual Studio version.

• OpenGL-compatible GPU and drivers

💡 If you're using Visual Studio 2022, make sure you're running CMake ≥ 3.21.1. Older versions (like 3.10 or 3.11) do not recognize VS 2022 and will fail to generate a solution.

Build Steps

1. Open a terminal (cmd or PowerShell) in the project root directory.
2. Run one of the provided batch scripts:
   • run_build_debug.bat
   • run_build_release.bat
3. Open the bin folder and run the executable or open the build folder and open the .sln file

Tip: Use the release build if you only need the final executable in optimized (Release) mode.

Build Instructions (Linux)

Prerequisites

Install dependencies:

sudo apt install build-essential cmake pkg-config git \
    libfreeimage-dev libglew-dev libglfw3-dev libgl1-mesa-dev \
    libxinerama-dev libxcursor-dev libxi-dev libxxf86vm-dev

Build Steps

1. Create and enter the build directory:

   mkdir build && cd build


2. Configure and build:

   cmake ..
   cmake --build . -j16


3. Run the executable located in the build directory.

Tip: Use cmake .. -DCMAKE_BUILD_TYPE=Release if you only need the final executable in optimized (Release) mode.

Limitations

• Volumetric Data such as foliage, grass, hair, clouds, etc. has not being targeted and will probably not be converted correctly if using primitives different from triangles.


How to Cite

To cite this repository, click the “Cite this repository” button at the top of the GitHub page.
Alternatively, you can use the following BibTeX entry:

@misc{
scolari2025mesh2splat,
author = {Scolari, Stefano},
title = {Mesh2Splat: Fast mesh to 3D Gaussian splat conversion},
year = {2025}, howpublished = {\url{https://github.com/electronicarts/mesh2splat}},
note = {Extended and updated version of the author's Master's thesis at KTH.}
}

This work builds upon the authors Master Thesis work:

@mastersthesis{
scolari2024thesis,
author = {Scolari, Stefano},
title = {Mesh2Splat: Gaussian Splatting from 3D Geometry and Materials},
school = {KTH Royal Institute of Technology},
year = {2024},
url = {https://urn.kb.se/resolve?urn=urn:nbn:se:kth:diva-359582}
}
