floooh/sokol

Simple STB-style cross-platform libraries for C and C++, written in C.

Sokol

See what's new (02-Jul-2026: the 'advanced swapchain config' update!)

Examples and Related Projects

• Live Samples via WASM (source)

• Doom Shareware ported to the Sokol headers (source)

• Syntonic Dentiforms Redux demo remaster by Aras Pranckevičius (blog post).

• Everybody Wants to Crank the World demo by Aras Pranckevičius, PC/web port via sokol (source).

• sokol_gp.h a 2D shape drawing library on top of sokol_gfx.h

• NanoVG backend a sokol_gfx backend for the amazing NanoVG library.

• Dear ImGui starterkit a self-contained starterkit for writing Dear ImGui apps in C.

• qoiview a basic viewer for the new QOI image file format

• Tiny 8-bit emulators

• A 'single-file' Pacman clone in C99, also available in Zig

• Soluna, a framework to make 2D games in Lua by @cloudwu

• Deep Future: ...and a game implemented with Soluna

• Solar Storm, a turn-based scifi artillery game built with Odin and Sokol, released on Steam.

• Spanking Runners (Samogonki), arcade racing in a bright and unusual world, released on Steam.

• MEG-4 a virtual fantasy console emulator in C89, ported to sokol

• A Minigolf game (source).

• hIghQube A game demo that used sokol rendering extensively

• Senos A music app that uses sokol as backend

• 'Dealer's Dungeon' (lower graphics quality, source)

• 'Brick Warrior' - a 1990's Breakout clone ported to Sokol :)

• LearnOpenGL examples ported to sokol-gfx (may be outdated) (git repo)

• Command line tools (shader compiler)

• How to build without a build system: useful details for integrating the Sokol headers into your own project with your favourite C/C++ build system

Core libraries

• sokol_gfx.h: 3D-API wrapper (GL/GLES3/WebGL2 + Metal + D3D11 + WebGPU)
• sokol_app.h: app framework wrapper (entry + window + 3D-context + input)
• sokol_time.h: time measurement
• sokol_audio.h: minimal buffer-streaming audio playback
• sokol_fetch.h: asynchronous data streaming from HTTP and local filesystem
• sokol_args.h: unified cmdline/URL arg parser for web and native apps
• sokol_log.h: provides a standard logging callback for the other sokol headers

Utility libraries

• sokol_imgui.h: sokol_gfx.h rendering backend for Dear ImGui
• sokol_nuklear.h: sokol_gfx.h rendering backend for Nuklear
• sokol_gl.h: OpenGL 1.x style immediate-mode rendering API on top of sokol_gfx.h
• sokol_fontstash.h: sokol_gl.h rendering backend for fontstash
• sokol_gfx_imgui.h: debug-inspection UI for sokol_gfx.h (implemented with Dear ImGui)
• sokol_app_imgui.h: debug-inspection UI for sokol_app.h (implemented with Dear ImGui)
• sokol_debugtext.h: a simple text renderer using vintage home computer fonts
• sokol_memtrack.h: easily track memory allocations in sokol headers
• sokol_shape.h: generate simple shapes and plug them into sokol-gfx resource creation structs
• sokol_color.h: X11 style color constants and functions for creating sg_color objects
• sokol_spine.h: a sokol-style wrapper around the Spine C runtime (http://en.esotericsoftware.com/spine-in-depth)
• sokol_letterbox.h: compute viewport params for rendering fixed-aspect-ratio content in a variable-aspect-ratio canvas
• sokol_framebuffer.h: provides CPU-framebuffers rendered via sokol_gfx.h

'Official' Language Bindings

These are automatically updated on changes to the C headers:

• sokol-zig
• sokol-odin
• sokol-nim
• sokol-rust
• sokol-d
• sokol-jai
• sokol-c3

Notes

WebAssembly is a 'first-class citizen', one important motivation for the Sokol headers is to provide a collection of cross-platform APIs with a minimal footprint on the web platform while still being useful.

The core headers are standalone and can be used independently from each other.

Why C:

• easier integration with other languages
• easier integration into other projects
• adds only minimal size overhead to executables

A blog post with more background info: A Tour of sokol_gfx.h

Quick build troubleshooting

When a first Sokol integration fails to compile or link, the problem is usually one of the following configuration mismatches:

• Define SOKOL_IMPL (or the per-header SOKOL_*_IMPL define) in exactly one C or C++ translation unit before including the Sokol headers. Other files should include the headers without the implementation define.
• Select exactly one rendering backend in that same implementation translation unit, for example SOKOL_GLCORE, SOKOL_GLES3, SOKOL_D3D11, SOKOL_METAL, SOKOL_WGPU or SOKOL_VULKAN. The backend define must match the shader code and any window/context setup code you use.
• If sokol_gfx.h and sokol_app.h are used together, use the same backend define for both headers. sokol_app.h creates the matching window and 3D API context; sokol_glue.h then forwards the platform-specific environment via sglue_environment() and sglue_swapchain().
• macOS and iOS builds which use sokol_app.h or Metal must compile the implementation file as Objective-C or Objective-C++ (.m or .mm, or the equivalent compiler flag), and link the frameworks listed in the header docs.
• Emscripten WebGL2 builds require the linker option -s USE_WEBGL2=1 when using SOKOL_GLES3. WebGPU builds use SOKOL_WGPU and need the WebGPU port/options described in the sokol_gfx.h header comments.
• On Linux, OpenGL builds commonly need the GL/X11 development packages installed by the platform package manager. SOKOL_GLCORE uses GLX by default; define SOKOL_FORCE_EGL if your build intentionally uses EGL instead.
• On Windows, MSVC and Clang builds usually pick up common system libraries via in-source #pragma comment(lib, ...) directives. MinGW/MSYS2 builds may need explicit linker flags such as -ld3d11 for SOKOL_D3D11.
• For shader-related errors, confirm that generated shader headers come from a sokol-shdc version compatible with the Sokol headers and were generated for the same backend(s) selected at compile time.

For exact per-header compiler and linker requirements, see the comment block at the top of each Sokol header and the build notes in sokol-samples.

sokol_gfx.h:

• simple, modern wrapper around GLES3/WebGL2, GL3.3, D3D11, Metal, and WebGPU
• buffers, images, shaders, pipeline-state-objects and render-passes
• does not handle window creation or 3D API context initialization
• does not provide shader dialect cross-translation (BUT there's now an 'official' shader-cross-compiler solution which seamlessly integrates with sokol_gfx.h and IDEs: see here for details

sokol_app.h

A minimal cross-platform application-wrapper library:

• unified application entry
• single window or canvas for 3D rendering
• 3D context initialization
• event-based keyboard, mouse and touch input
• supported platforms: Win32, MacOS, Linux (X11), iOS, WASM, Android, UWP
• supported 3D-APIs: GL3.3 (GLX/WGL), Metal, D3D11, GLES3/WebGL2

The vanilla Hello-Triangle using sokol_gfx.h, sokol_app.h and the sokol-shdc shader compiler (shader code not shown):

#include "sokol_app.h"
#include "sokol_gfx.h"
#include "sokol_log.h"
#include "sokol_glue.h"
#include "triangle-sapp.glsl.h"

static struct {
    sg_pipeline pip;
    sg_bindings bind;
    sg_pass_action pass_action;
} state;

static void init(void) {
    sg_setup(&(sg_desc){
        .environment = sglue_environment(),
        .logger.func = slog_func,
    });

    float vertices[] = {
         0.0f,  0.5f, 0.5f,     1.0f, 0.0f, 0.0f, 1.0f,
         0.5f, -0.5f, 0.5f,     0.0f, 1.0f, 0.0f, 1.0f,
        -0.5f, -0.5f, 0.5f,     0.0f, 0.0f, 1.0f, 1.0f
    };
    state.bind.vertex_buffers[0] = sg_make_buffer(&(sg_buffer_desc){
        .data = SG_RANGE(vertices),
    });

    state.pip = sg_make_pipeline(&(sg_pipeline_desc){
        .shader = sg_make_shader(triangle_shader_desc(sg_query_backend())),
        .layout = {
            .attrs = {
                [ATTR_triangle_position].format = SG_VERTEXFORMAT_FLOAT3,
                [ATTR_triangle_color0].format = SG_VERTEXFORMAT_FLOAT4
            }
        },
    });

    state.pass_action = (sg_pass_action) {
        .colors[0] = { .load_action=SG_LOADACTION_CLEAR, .clear_value={0.0f, 0.0f, 0.0f, 1.0f } }
    };
}

void frame(void) {
    sg_begin_pass(&(sg_pass){ .action = state.pass_action, .swapchain = sglue_swapchain() });
    sg_apply_pipeline(state.pip);
    sg_apply_bindings(&state.bind);
    sg_draw(0, 3, 1);
    sg_end_pass();
    sg_commit();
}

void cleanup(void) {
    sg_shutdown();
}

sapp_desc sokol_main(int argc, char* argv[]) {
    (void)argc; (void)argv;
    return (sapp_desc){
        .init_cb = init,
        .frame_cb = frame,
        .cleanup_cb = cleanup,
        .width = 640,
        .height = 480,
        .window_title = "Triangle",
        .icon.sokol_default = true,
        .logger.func = slog_func,
    };
}

sokol_audio.h

A minimal audio-streaming API:

• you provide a mono- or stereo-stream of 32-bit float samples which sokol_audio.h forwards into platform-specific backends
• two ways to provide the data:
  1. directly fill backend audio buffer from your callback function running in the audio thread
  2. alternatively push small packets of audio data from your main loop, or a separate thread created by you
• platform backends:
  • Windows: WASAPI
  • macOS/iOS: CoreAudio
  • Linux: ALSA
  • emscripten: WebAudio + ScriptProcessorNode (doesn't use the emscripten-provided OpenAL or SDL Audio wrappers)

A simple mono square-wave generator using the callback model:

// the sample callback, running in audio thread
static void stream_cb(float* buffer, int num_frames, int num_channels) {
    assert(1 == num_channels);
    static uint32_t count = 0;
    for (int i = 0; i < num_frames; i++) {
        buffer[i] = (count++ & (1<<3)) ? 0.5f : -0.5f;
    }
}

int main() {
    // init sokol-audio with default params
    saudio_setup(&(saudio_desc){
        .stream_cb = stream_cb,
        .logger.func = slog_func,
    });

    // run main loop
    ...

    // shutdown sokol-audio
    saudio_shutdown();
    return 0;

The same code using the push-model

#define BUF_SIZE (32)
int main() {
    // init sokol-audio with default params, no callback
    saudio_setup(&(saudio_desc){
        .logger.func = slog_func,
    });
    assert(saudio_channels() == 1);

    // a small intermediate buffer so we don't need to push
    // individual samples, which would be quite inefficient
    float buf[BUF_SIZE];
    int buf_pos = 0;
    uint32_t count = 0;

    // push samples from main loop
    bool done = false;
    while (!done) {
        // generate and push audio samples...
        int num_frames = saudio_expect();
        for (int i = 0; i < num_frames; i++) {
            // simple square wave generator
            buf[buf_pos++] = (count++ & (1<<3)) ? 0.5f : -0.5f;
            if (buf_pos == BUF_SIZE) {
                buf_pos = 0;
                saudio_push(buf, BUF_SIZE);
            }
        }
        // handle other per-frame stuff...
        ...
    }

    // shutdown sokol-audio
    saudio_shutdown();
    return 0;
}

sokol_fetch.h

Load entire files, or stream data asynchronously over HTTP (emscripten/wasm) or the local filesystem (all native platforms).

Simple C99 example loading a file into a static buffer:

#include "sokol_fetch.h"
#include "sokol_log.h"

static void response_callback(const sfetch_response*);

#define MAX_FILE_SIZE (1024*1024)
static uint8_t buffer[MAX_FILE_SIZE];

// application init
static void init(void) {
    ...
    // setup sokol-fetch with default config:
    sfetch_setup(&(sfetch_desc_t){ .logger.func = slog_func });

    // start loading a file into a statically allocated buffer:
    sfetch_send(&(sfetch_request_t){
        .path = "hello_world.txt",
        .callback = response_callback
        .buffer_ptr = buffer,
        .buffer_size = sizeof(buffer)
    });
}

// per frame...
static void frame(void) {
    ...
    // need to call sfetch_dowork() once per frame to 'turn the gears':
    sfetch_dowork();
    ...
}

// the response callback is where the interesting stuff happens:
static void response_callback(const sfetch_response_t* response) {
    if (response->fetched) {
        // data has been loaded into the provided buffer, do something
        // with the data...
        const void* data = response->buffer_ptr;
        uint64_t data_size = response->fetched_size;
    }
    // the finished flag is set both on success and failure
    if (response->failed) {
        // oops, something went wrong
        switch (response->error_code) {
            SFETCH_ERROR_FILE_NOT_FOUND: ...
            SFETCH_ERROR_BUFFER_TOO_SMALL: ...
            ...
        }
    }
}

// application shutdown
static void shutdown(void) {
    ...
    sfetch_shutdown();
    ...
}

sokol_time.h:

Simple cross-platform time measurement:

#include "sokol_time.h"
...
/* initialize sokol_time */
stm_setup();

/* take start timestamp */
uint64_t start = stm_now();

...some code to measure...

/* compute elapsed time */
uint64_t elapsed = stm_since(start);

/* convert to time units */
double seconds = stm_sec(elapsed);
double milliseconds = stm_ms(elapsed);
double microseconds = stm_us(elapsed);
double nanoseconds = stm_ns(elapsed);

/* difference between 2 time stamps */
uint64_t start = stm_now();
...
uint64_t end = stm_now();
uint64_t elapsed = stm_diff(end, start);

/* compute a 'lap time' (e.g. for fps) */
uint64_t last_time = 0;
while (!done) {
    ...render something...
    double frame_time_ms = stm_ms(stm_laptime(&last_time));
}

sokol_args.h

Unified argument parsing for web and native apps. Uses argc/argv on native platforms and the URL query string on the web.

Example URL with one arg:

https://floooh.github.io/tiny8bit/kc85.html?type=kc85_4

The same as command line app:

kc85 type=kc85_4

Parsed like this:

#include "sokol_args.h"

int main(int argc, char* argv[]) {
    sargs_setup(&(sargs_desc){ .argc=argc, .argv=argv });
    if (sargs_exists("type")) {
        if (sargs_equals("type", "kc85_4")) {
            // start as KC85/4
        }
        else if (sargs_equals("type", "kc85_3")) {
            // start as KC85/3
        }
        else {
            // start as KC85/2
        }
    }
    sargs_shutdown();
    return 0;
}

See the sokol_args.h header for a more complete documentation, and the Tiny Emulators for more interesting usage examples.
