ORBIT
This project is not maintained by Google engineers anymore at this point.
Orbit, the Open Runtime Binary Instrumentation Tool is a
standalone native application profiler for Windows and Linux. It supports
native applications written in languages such as C, C++, Rust, or Go. Its main
purpose is to help developers identify the performance bottlenecks of a complex
application. Orbit can be also used to visualize the execution flow of such
applications.
The key differentiator with many existing tools is that no alteration to the
target process is necessary. Orbit does not require you to change a single line
of code. It doesn't require you to recompile or even relaunch the application
you want to profile. Everything is done seamlessly, right when you need it. It
requires zero integration time and zero iteration time.
Orbit combines sampling and dynamic instrumentation to optimize the profiling
workflow. Sampling can quickly identify interesting functions to instrument.
Dynamic instrumentation results in exact function entry and exit information
which is presented in the form of per-thread hierarchical call graphs.
Manual instrumentation markers can be added to the source code and further
allows for value-tracking. Scheduling events are also shown to visualize when a
thread was running and on what core. Furthermore, Orbit visualizes thread
dependencies, showing which thread got blocked or unblocked by which other
thread. For AMD GPUs, the submission, scheduling and hardware execution timings
of a job is visualized. Additional GPU data, such as Vulkan debug markers can be
retrieved using Orbit's Vulkan layer. Memory consumption and page-fault
information is visualized as well.
An introduction to Orbit's key features can be found in the following YouTube
video:
Features
- Dynamic Instrumentation (no code change required)
- Callstack Sampling
- Wine/Proton Mixed-Callstack Profiling
- Thread Scheduling and Dependency Tracing
- Memory Tracing
- GPU Driver Tracepoints (AMD only)
- Vulkan Debug Label and Command Buffer Tracing (AMD only)
- Manual Instrumentation
- Source Code and Disassembly View
- Remote Profiling
- Debug Symbol Parsing (ELF, DWARF, PE and PDB)
- Full Serialization of Captured Data
Note
Orbit's focus has shifted to the Linux version. Windows local profiling is
currently only supported partially and major features, such as dynamic
instrumentation, are not yet implemented. It is possible however to profile
Linux executables from a Windows UI instance. For Windows local profiling,
you can still use the released
binaries, but please note that
they are deprecated and mostly undocumented.
Build
Please have a look at the first three sections of our
development documentation. It describes how to build Orbit and
which compilers, platforms, and tools are supported and needed.
Workflow
Note An extensive documentation of the usage of Orbit can be found in our
usage documentation.
The following describes the basic workflow of Orbit:
- Select a process in the list of currently running processes in the connection
setup dialog, and click Start Session.
- The list of loaded modules will appear at the top of the Symbols tab.
- Orbit tries to automatically retrieve debug information of the modules.
See here on how to load
symbols for modules Orbit failed to load. For successfully loaded module
symbols, the Functions tab will get populated.
- Select functions you wish to dynamically instrument in the Functions tab
by Right-Click and choosing Hook.
- Start profiling by pressing F5. To stop profiling, press
F5 again. You can either zoom time using W and
S or Ctrl + the scroll wheel. You can also
Ctrl+Right-Click and drag to zoom to a specific time
range. To scale the UI, press Ctrl + +/-.
Press SPACE to see the last 2 seconds of capture.
- You can select sections of the per-thread sampling event track to get a
sampling report of your selection.
Presets
Once you have loaded the debug information for your modules and have chosen
functions of interest to dynamically instrument, you can save your profiling
preset so that you won't have to do this manually again. To save a preset, go to
File > Save Preset
Feedback
Questions and comments are more than welcome: please open an
issue.
About
Orbit was created by Pierric Gimmig. It was
further developed and maintained by a team of engineers at Google. As of now, the
project is however not being maintained by Google engineers anymore.
The following people worked on Orbit:
- @akopich
- @antonrohr
- @beckerhe
- @danielfenner
- @dimitry-
- @dpallotti
- @florian-kuebler
- @karupayun
- @pierricgimmig
- @reichlfl
- @ronaldfw
- @vickyliu-go4it
- @vwbaker
