HubSpot/BuckyClient

Bucky

Bucky is a client and server for sending performance data from the client into statsd+graphite, OpenTSDB, or any other stats aggregator of your choice.

It can automatically measure how long your pages take to load, how long AJAX requests take and how long various functions take to run. Most importantly, it's taking the measurements on actual page loads, so the data has the potential to be much more valuable than in vitro measurements.

If you already use statsd or OpenTSDB, you can get started in just a few minutes. If you're not collecting stats, you should start! What gets measured gets managed.

Server

You can play with Bucky just using the client, but if you'd like to start collecting data, see the Server Instructions.

Setup

From The Client

Include bucky.js on your page, the only required config can be done right in the script tag:

<script src="bucky.js" data-bucky-host="/bucky" data-bucky-page data-bucky-requests></script>

That config will automatically log the performance of your page and all the requests you make to a server running at /bucky. It will automatically decide the right key name based on the url of the page. If you'd like, you can also specify it manually:

<script src="bucky.js" data-bucky-host="/bucky" data-bucky-page="index" data-bucky-requests="index"></script>

The Bucky object will be available globally, but there is nothing you need to call for basic usage.

Bucky can also be loaded with AMD or Browserify (see the methods below).

From Node

npm install bucky

bucky = require('bucky')

Configuring

Before sending any data, call setOptions if you're not using the data- attribute based configuration:

Bucky.setOptions({
  host: 'http://myweb.site:9999/bucky'
});

Some options you might be interested in:

• host: Where we can reach your Bucky server, including the APP_ROOT.

  The Bucky server has a very liberal CORS config, so we should be able to connect to it even if it's on a different domain, but hosting it on the same domain and port will save you some preflight requests.

• active: Should Bucky actually send data? Use this to disable Bucky during local dev for example.

• sample: What fraction of clients should actually send data? Use to subsample your clients if you have too much data coming in.

Take a look at the source for a full list of options.

Sending Page Performance

Modern browsers log a bunch of page performance data, bucky includes a method for writing all of this in one go. It won't do anything on browsers which don't support the performance.timing api. Call it whenever, it will bind an event if the data isn't ready yet.

Bucky.sendPagePerformance('where.the.data.should.go')

Setting data-bucky-page triggers this automatically.

The two most relevant stats provided are responseEnd which is the amount of time it took for the original page to be loaded and domInteractive which is the amount of time before the page has finished loaded and can be interacted with by the user.

As a reminder: this data is browser specific, so it will likely skew lower than what users on old browsers see.

If you're using Backbone, it might be a good idea to send your data based on route:

Backbone.history.on 'route', (router, route) ->
   # Will only send on the initial page load:
   Bucky.sendPagePerformance("some.location.page.#{ route }")

The data collected will look something like this:

pages.contactDetail.timing.connectEnd: "172.000|ms"
pages.contactDetail.timing.connectStart: "106.000|ms"
pages.contactDetail.timing.domComplete: "1029.000|ms"
pages.contactDetail.timing.domContentLoadedEventEnd: "1019.000|ms"
pages.contactDetail.timing.domContentLoadedEventStart: "980.000|ms"
pages.contactDetail.timing.domInteractive: "980.000|ms"
pages.contactDetail.timing.domLoading: "254.000|ms"
pages.contactDetail.timing.domainLookupEnd: "106.000|ms"
pages.contactDetail.timing.domainLookupStart: "106.000|ms"
pages.contactDetail.timing.fetchStart: "103.000|ms"
pages.contactDetail.timing.loadEventEnd: "1030.000|ms"
pages.contactDetail.timing.loadEventStart: "1029.000|ms"
pages.contactDetail.timing.navigationStart: "0.000|ms"
pages.contactDetail.timing.requestStart: "173.000|ms"
pages.contactDetail.timing.responseEnd: "243.000|ms"
pages.contactDetail.timing.responseStart: "235.000|ms"
pages.contactDetail.timing.secureConnectionStart: "106.000|ms"

A description of what each datapoint represents is included in the spec.

Sending AJAX Request Time

Bucky can automatically log all ajax requests made by hooking into XMLHttpRequest and doing some transformations on the url to try and create a graphite key from it. Enable it as early in your app's load as is possible:

Bucky.requests.monitor('my.project.requests')

Setting data-bucky-requests calls this automatically.

The data collected will look something like this for a GET request to api.hubapi.com/automation/v2/workflows:

contacts.web.prod.requests.api.hubapi.automation.v2.workflows.get: "656.794|ms"
contacts.web.prod.requests.api.hubapi.automation.v2.workflows.get.2xx: "1|c"
contacts.web.prod.requests.api.hubapi.automation.v2.workflows.get.200: "1|c"
contacts.web.prod.requests.api.hubapi.automation.v2.workflows.get.headers: "436.737|ms"
contacts.web.prod.requests.api.hubapi.automation.v2.workflows.get.receiving: "0.182|ms"
contacts.web.prod.requests.api.hubapi.automation.v2.workflows.get.sending: "0.059|ms"
contacts.web.prod.requests.api.hubapi.automation.v2.workflows.get.waiting: "206.035|ms"

Prefixing

You can build a client which will prefix all of your datapoints by calling bucky as a function:

myBucky = Bucky('awesome.app.view')

# You can then use all of the normal methods:
myBucky.send('data.point', 5)

You can repeatedly call clients to add more prefixes:

contactsBucky = bucky('contacts')
cwBucky = contactsBucky('web')

cwBucky.send('x', 1) # Data goes in contacts.web.x

Counting Things

By default send sends absolute values, this is rarely what you want when working from the client, incrementing a counter is usually more helpful:

bucky.count('my.awesome.thing')
bucky.count('number.of.chips.eaten', 5)

Timing Things

You can manually send ms durations using timer.send:

bucky.timer.send('timed.thing', 55)

Bucky includes a method to time async functions:

bucky.timer.time 'my.awesome.function', (done) ->
  asyncThingy ->
    done()

You can also manually start and stop your timer:

bucky.timer.start 'my.awesome.function'

asyncThingy ->
  bucky.timer.stop 'my.awesome.function'

You can time synchronous functions as well:

bucky.timer.timeSync 'my.awesome.function', ->
  Math.sqrt(100)

The time and timeSync functions also accept a context and arguments to pass to the called function:

bucky.timer.timeSync 'my.render.function', @render, @, arg1, arg2

You can wrap existing functions using wrap:

func = bucky.timer.wrap('func.time', func)

It also supports a special syntax for methods:

class SomeClass
  render: bucky.timer.wrap('render') ->
    # Normal render stuff

Note that this wrapping does not play nice with CoffeeScript super calls.

Bucky also includes a function for measuring the time since the navigationStart event was fired (the beginning of the request):

bucky.timer.mark('my.thing.happened')

It acts like a timer where the start is always navigation start.

The stopwatch method allows you to begin a timer which can be stopped multiple times:

watch = bucky.stopwatch('some.prefix.if.you.want')

You can then call watch.mark('key') to send the time since the stopwatch started, or watch.split('key') to send the time since the last split.

Sending Points

If you want to send absolute values (rare from the client), you can use send directly.

The one use we've had for this is sending +new Date from every client to get an idea of how skewed their clocks are.

Bucky.send 'my.awesome.datapoint', 2432.43434

Your Stats

You can find your stats in the stats and stats.timing folders in graphite, or as written in OpenTSDB.

Send Frequency

Bucky will send your data in bulk from the client either five seconds after the last datapoint is added, or thirty seconds after the last send, whichever comes first. If you log multiple datapoints within this send frequency, the points will be averaged (and the appropriate frequency information will be sent to statsd) (with the exception of counters, they are incremented). This means that the max and min numbers you get from statsd actually represent the max and min 5-30 second bucket. Note that this is per-client, not for the entire bucky process (it's generally only important on the server where you might be pushing out many points with the same key).

Bucky Object

The Bucky object provides a couple extra properties you can access:

• Bucky.history: The history of all datapoints ever sent.
• Bucky.active: Is Bucky sending data? This can change if you change the active or sample settings.
• Bucky.flush(): Send the Bucky queue immediately
• Bucky.timer.now(): A clock based on the most precise time available (not guarenteed to be from the epoch)

URL -> Key Transformation

request.monitor attempts to automatically transform your urls into keys. It does a bunch of transformations with the goal of removing anything which will vary per-request, so you end up with stats per-endpoint. These tranformations include:

• Stripping GUIDS, IDs, SHA1s, MD5s
• Stripping email addresses
• Stripping domains

If you find these tranformations too invasive, or not invasive enough, you can modify them.

// You can diable tranforms with `.disable`
Bucky.requests.transforms.disable('guid');

// You can enable transforms with `.enable`
Bucky.requests.tranforms.enable('guid');

// `.enable` can also be used to add a new tranform:
Bucky.requests.transforms.enable('my-ids', /[0-9]{4}-[0-9]{12}/g)

// The third argument defines what the match is replaced with (rather than just eliminating it):
Bucky.requests.transforms.enable('campaign', /campaigns\/\w{15}/ig, '/campaigns')

// You can also just provide a function which takes in the url, and returns it modified:
Bucky.request.transforms.enable('soup', function(url){ return url.split('').reverse().join(''); })

Enabled tests will be added to the beginning of the enabled list, meaning they will be executed before any other tranform. Edit the Bucky.requests.tranforms.enabled array if you need more specific control.

The order of the transforms is very important. If you, for example, were to run the id transform before the guid one, the guid transform wouldn't match any guid which began with a number (as the number would have already been stripped out, making the guid the wrong length).

When you first enable request monitoring, it's a good idea to keep an eye on the Bucky logs to get an idea of what sort of data points are being created.

App Server

This project pushes data to the Bucky Server.

Server Documentation
