jpetazzo/pxe

My other PXE server is a container

This is a Dockerfile to build a container running a PXE server, pre-configured to serve a Debian netinstall kernel and initrd.

Quick start

1. Of course you need Docker first!
2. Clone this repo and cd into the repo checkout.
3. Build the container with docker build -t pxe .
4. Run the container with PXECID=$(docker run --cap-add NET_ADMIN -d pxe)
5. Give it an extra network interface with ./pipework br0 $PXECID 192.168.242.1/24
6. Put the network interface connected to your machines on the same bridge with e.g. brctl addif br0 eth0 (don't forget to move eth0 IP address to br0 if there is one).
7. You can now boot PXE machines on the network connected to eth0! Alternatively, you can put VMs on br0 and achieve the same result.

Why and how do we move eth0 IP address to br0?

The Linux network stack has the notion of master and slave interfaces. They are used in many places, including bridges and bonding (when multiple physical interfaces are grouped together to form a single logical link, for increased throughput or reliability). When using Linux bridges, the bridge is the master interface, and all the ports of the bridge are slave interfaces.

Now is the tricky part: with interfaces like bridges and bonding groups, only the master should have IP addresses; not the slaves. If an IP address is configured on a slave interface, it will misbehave in seemingly random ways. For instance, it can stop working if the interface is down (but the master interface is still up). Or it might handle some protocols like ARP only for packets inbound on this interface.

Therefore, when changing the configuration of an existing interface to place it inside a bridge (or bonding group), you should deconfigure its IP address, and assign it to the master interface instead. I recommend the following steps:

1. Check the IP address of the interface (with e.g. ip addr ls eth0). Carefully note the IP address and its subnet mask, e.g. 192.168.1.4/24. There can be multiple addresses; in that case, note all of them.
2. Check if there are special routes going through that interface. Chances are, that there is a default route, and you will have to take care of it; otherwise you will lose internet connectivity. The easiest way is to do ip route ls dev eth0. You will almost certainly see an entry with proto kernel scope link, which is the automatic entry corresponding to the subnet directly connected to this interface. You can ignore this one. However, if you see something like default via 192.168.1.1, note it.
3. Deconfigure the IP address. In that case, we would do ip addr del 192.168.1.4/24 dev eth0. You don't havea to deconfigure the routes: they will be automatically removed as the address is withdrawn.
4. Configure the IP address on the bridge. In our example, that would be ip addr add 192.168.1.4/24 dev br0.
5. Last but not least, re-add the routes on the bridge. Here, we would do ip route add default via 192.168.1.1.

If you want to do that automatically at boot, you can do it through the /etc/network/interfaces file (on Debian/Ubuntu).

It will look like this (assuming the same IP addresses than our previous example):

auto br0
iface br0 inet static
      address 192.168.1.4
      netmask 255.255.255.0
      network 192.168.1.0
      broadcast 192.168.1.255
      gateway 192.168.1.1
      bridge_ports eth0
      bridge_stp off
      bridge_fd 0

Don't forget to disable the section related to eth0 then!

I want to netboot something else!

Left as an exercise for the reader. Check the Dockerfile and rebuild; it should be easy enough.

If you want to boot coreOS, check out avlis/pxe_coreos

It doesn't work!

That's unfortunate. You should probably adapt these instructions to use host networking (i.e. --net host) since this recipe was written before host networking was available. Meanwhile, if you have strange symptoms (like, some things ping and some don't) you might have to disable bridge netfilter filtering. Please look at issue #17 for more details.

Can I change the IP address, 192.168.242.1...?

Yes. Be aware that the DHCP server on this container will offer IPs from 101 to 199 on the same /24 subnet. So make sure that the IP you give to the container via pipework does not clash with that. Also make sure that there are no other hosts on that bridge within that range. Otherwise, change it in the Dockerfile, check the line that says --dhcp-range=(...).

Can I not use pipework?

Yes, but it will be more complicated. You will have to:

• make sure that Docker UDP can handle broadcast packets (since PXE/DHCP uses broadcast packets);
• make sure that UDP ports are correctly mapped;
• auto-detect the gateway address and DNS server, instead of using the container as a router+DNS server;
• maybe something else that I overlooked.

I want MOAR fun!

Let's have a game!

1. Burn a boot2docker ISO on a blank CD.
2. With that CD, boot a physical machine.
3. Run the PXE container on Docker on the physical machine.
4. Pull the ubuntu container, start it in privileged mode, apt-get install QEMU in it, and start a QEMU VM, mapping its hard disks to the real hard disk of the machine, and bridging it with the PXE container.
5. The QEMU VM will netboot from the PXE container. Install Debian.
6. Reboot the physical machine -- it now boots on Debian.
7. Repeat steps but install Windows for trolling purposes.

Did anyone make something useful with this?

Yes!

• @dreamcat4 used this as inspiration for a bunch of pxe images
• @kkredit used this as the basis for a CI setup tied to Jenkins and multiple hardware targets
• _________ (insert your name here, by submitting a PR to this README file! ;-))
