ketoo/NoahGameFrame

2021.7.9 在新西兰奥克兰的一场车祸中，ketoo 永远离开了我们。

On July 9, 2021, ketoo left us forever in a car accident in Auckland, New Zealand.

由于mater有权限合并了， master-new 分支后续不再维护。 直接维护master即可，pr也提交到master即可

Since mater has permission to merge, the master-new branch will no longer be maintained. You can directly maintain the master, and the pr can also be submitted to the master

NoahGameFrame

• develop
• master
• chat

#####QQ群：330241037

Tutorial && Documents

https://github.com/ketoo/NoahGameFrame/wiki

What is NoahGameFrame?

NoahGameFrame (NF) is a lightweight, fast, scalable, distributed plugin framework. NF is greatly inspired by OGRE and Bigworld.

Features

• Easy-to-use, interface-oriented design
• An extensible plugin framework that makes getting your application running quick and easy
• A clean, uncluttered design and stable engine that has been used in several commercial products
• A high performance actor model (by a safe thread pool)
• Event and attribute-driven, making it clear and easy to maintain your business
• Based on standard C++ development, ensuring cross-platform support
• An existing C++ and C# game client for rapid development
• Cross-platform support

Tutorial && Documents

https://github.com/ketoo/NoahGameFrame/wiki

Architecture

App Architecture:

Server Architecture

Get the Sources:

git clone https://github.com/ketoo/NoahGameFrame.git

or

svn checkout https://github.com/ketoo/NoahGameFrame

Dependencies

• libevent
• easylogging++
• google protobuf
• hiredis
• ajson
• concurrentqueue
• RapidXML
• LuaIntf
• navigation
• lua

Tutorial && Documents

https://github.com/ketoo/NoahGameFrame/wiki

IF YOU CAN NOT BUILD THE DEPENDENCIES THEN PLEASE RUN THE CMDS BELOW TO SET UP THE ENVIRONMENT:

• sudo apt-get install g++
• sudo apt-get install cmake
• sudo apt-get install automake
• sudo apt-get install zip unzip

Supported Compilers

• GCC >= 7 (Tested on Ubuntu 16.04)
• MSVC >= VS2019 (Tested on Win10)

Build and Install

FOR WINDOWS, MSVC >= 2019

1. Git pull all source
2. Run the script file named build_dep.bat where located /Dependencies (墙内上网的同学请点击：墙内下载依赖库.bat)
3. Build the solution(if u build failed, please build again(not rebuild all))
4. Run the binary file by _Out/rund.bat

FOR LINUX(UBUNTU, CENTOS) ---- please use administrator(or sudo) to do these:

1. Git pull all source
2. Run install4cmake.sh to build NF (or run cd /Dependencies ./build_dep.sh then run buildServer.sh)
3. Run the binary file by _Out/rund.sh

IF YOU LIVING IN A COUNTRY CANNOT ACCESS GITHUB FASTLY PLZ BUILD NF WITH VPN

HOW TO RUN HELLO WORLD

https://github.com/ketoo/NoahGameFrame/wiki/How-to-run-the-Helloworld

HOW TO DEBUG WITH UNITY3D

https://github.com/ketoo/NoahGameFrame/wiki/How-to-debug-with-unity3d

Unity Multiplayer Demo

WebSite: https://github.com/ketoo/NFUnitySDK

Tutorial && Documents

https://github.com/ketoo/NoahGameFrame/wiki

License

The NFrame project is currently available under the Apache License.

Tutorial:

01-Hello world, add a module

// -------------------------------------------------------------------------
//    @FileName      	:    HelloWorld1.h
//    @Author           :    ketoo
//    @Date             :    2014-05-01 08:51
//    @Module           :   HelloWorld1
//
// -------------------------------------------------------------------------

#ifndef NFC_HELLO_WORLD1_H
#define NFC_HELLO_WORLD1_H

#include "NFComm/NFPluginModule/NFIPluginManager.h"

class HelloWorld1
    : public NFIModule
{
public:
    HelloWorld1(NFIPluginManager* p)
    {
        pPluginManager = p;
    }

    virtual bool Init();
    virtual bool AfterInit();

    virtual bool Execute();

    virtual bool BeforeShut();
    virtual bool Shut();

protected:

};

#endif


#include "HelloWorld1.h"

bool HelloWorld1::Init()
{
    // Use this for initialization

    std::cout << "Hello, world1, Init" << std::endl;

    return true;
}

bool HelloWorld1::AfterInit()
{
    // AfterInit is called after Init

    std::cout << "Hello, world1, AfterInit" << std::endl;

    return true;
}

bool HelloWorld1::Execute()
{
    // Execute is called once per frame

    //std::cout << "Hello, world1, Execute" << std::endl;

    return true;
}

bool HelloWorld1::BeforeShut()
{
    //before final

    std::cout << "Hello, world1, BeforeShut" << std::endl;

    return true;
}

bool HelloWorld1::Shut()
{
    //final

    std::cout << "Hello, world1, Shut" << std::endl;

    return true;
}

---

02-Hello world, test data driver

• how to use the world's most advanced data engine

---

03-Hello world, test heartbeat and event system

• how to use the synchronous events

---

04-Hello actor, test actor model(async event system)

• how to use the asynchronous events
• use multiple cpus to get high performance

How to Create a New LuaScriptModule

Step 1

Create a Lua Script File, and Must Contain following functions

• awake()

• init()

• ready_execute()

• after_init()

• before_shut()

• shut()

Mostly like this

test_module.lua

test_module = {}
register_module(test_module,"test_module");


function test_module.awake()

end

function test_module.init()
end

function test_module.after_init()
end

function test_module.ready_execute()
end

function test_module.before_shut()
end

function test_module.shut()
end

##Step 2 Add your LuaScriptModule Infomation into script_list.lua

ScriptList={
    {tbl=nil, tblName="TestModule"},
    {tbl=nil, tblName="TestModule2"},
}

load_script_file(ScriptList)

##Hot fix Add your lua script file name on here script_reload.lua

---

New Feature in future: Blue Print System

Demo:

---

Amazing open source projects:

breeze

• Auther: zsummer
• Github: https://github.com/zsummer/breeze
• Description:A fast, scalable, distributed game server framework for C++

gce

• Auther: nousxiong
• GitHub: https://github.com/nousxiong/gce
• Description: The Game Communication Environment (GCE) is an actor model framework for online game development.

moon

• Auther: bruce
• GitHub: https://github.com/sniper00/moon.git
• Description: A cross-platform,lightweight,scalable game server framework written in C++, and suport Lua Script.

Tutorial && Documents

https://github.com/ketoo/NoahGameFrame/wiki
