knadh/otpgateway

OTP Gateway

OTP (One Time Password) Gateway is a standalone web server that provides a central gateway to verify user addresses such as e-mails and phone numbers, and to send 2FA confirmations to such addresses.

• Use the built in web UI to easily integrate with existing applications.
• Use the HTTP/JSON APIs to build your own UI.
• Basic multi-tenancy with namespace+secret BasicAuth for seggregating applications.

Built-in providers

• SMTP
• AWS Pinpoint SMS
• Kaleyra SMS, WhatsApp

Webhook providers

Any external provider can be integrated by defining one or more webhook providers in the config. A JSON payload is posted to the webhook endpoint whenever an OTP is generated.

How does it work?

The application is agnostic of the user's "address" and the OTP / verification codes. These are handled by providers.

• Addresses are strings, for example, e-mail IDs, phone numbers, bank account numbers etc.
• OTPs are also just strings, for instance, 6 digit codes sent as SMSes or a penny value dropped to a bank account.

The gateway sends the OTP value to the user's address using a provider (an upstream that takes the OTP + message and sends it to the user) and the user then has to read the OTP and enter it on the gateway's web view to complete the verification.

Usage

Download the latest release from the releases page.

• Copy config.sample.toml to config.toml and edit the configuration.
• Run ./otpgateway
• Refer to the API reference to send OTPs.

Built in UI

1. Generate an OTP for a user server side in your application: curl -u "myAppName:mySecret" -X PUT -d "[email protected]&provider=smtp" localhost:9000/api/otp/uniqueIDForJohnDoe
2. Use the OTPGateway() Javascript function (see the Javascript plugin section) to initiate the modal UI on your webpage. On receiving the Javascript callback, post it back to your application and confirm that the OTP is indeed verified: curl -u "myAppName:mySecret" -X POST localhost:9000/api/otp/uniqueIDForJohnDoe/status

Your own UI

Use the APIs described below to build your own UI.

API reference

List providers

curl -u "myAppName:mySecret" localhost:9000/api/providers

{
  "status": "success",
  "data": ["smtp"]
}

Initiate an OTP for a user

curl -u "myAppName:mySecret" -X PUT -d "[email protected]&provider=smtp&extra={\"yes\": true}" localhost:9000/api/otp/uniqueIDForJohnDoe

{
  "status": "success",
  "data": {
    "namespace": "myAppName",
    "id": "uniqueIDForJohnDoe",
    "to": "[email protected]",
    "channel_description": "",
    "address_description": "",
    "extra": { "yes": true },
    "provider": "smtp",
    "otp": "354965",
    "max_attempts": 5,
    "attempts": 5,
    "closed": false,
    "ttl": 300,
    "url": "http://localhost:9000/otp/myAppName/uniqueIDForJohnDoe"
  }
}

Validate an OTP entered by the user

Every incorrect validation here increments the attempts before further attempts are blocked. Once the OTP is verified, it is deleted, unless skip_delete=true is passed in the params. curl -u "myAppName:mySecret" -X POST -d "action=check&otp=354965" localhost:9000/api/otp/uniqueIDForJohnDoe

{
  "status": "success",
  "data": {
    "namespace": "myAppName",
    "id": "uniqueIDForJohnDoe",
    "to": "[email protected]",
    "channel_description": "",
    "address_description": "",
    "extra": { "yes": true },
    "provider": "smtp",
    "otp": "354965",
    "max_attempts": 5,
    "attempts": 5,
    "closed": false,
    "ttl": 300,
    "url": "http://localhost:9000/otp/myAppName/uniqueIDForJohnDoe"
  }
}

Check whether an OTP request is verified

This is used to confirm verification after a callback from the built in UI flow. curl -u "myAppName:mySecret" -X POST localhost:9000/api/otp/uniqueIDForJohnDoe/status

{
  "status": "success",
  "data": {
    "namespace": "myAppName",
    "id": "uniqueIDForJohnDoe",
    "to": "[email protected]",
    "channel_description": "",
    "address_description": "",
    "extra": { "yes": true },
    "provider": "smtp",
    "otp": "354965",
    "max_attempts": 5,
    "attempts": 5,
    "closed": false,
    "ttl": 300
  }
}

or an error such as

{ "status": "error", "message": "OTP not verified" }

The closed field indicates whether the OTP has been validated by the user and has been "closed".

Javascript plugin

The gateway comes with a Javascript plugin that enables easy integration of the verification UI into existing applications. Once a server side call to generate an OTP is made and a namespace and id are obtained, calling OTPGateway() opens the verification UI in a modal popup. Upon completion of verification by the user, a callback is triggered.

<!-- The id #otpgateway-script is required for the script to work //-->
<script
  id="otpgateway-script"
  src="http://localhost:9000/static/otp.js"
></script>
<script>
  // 1. Make a call to the server to generate and send an OTP and return the
  // the :namespace and :id for the OTP.
  // 2. Invoke the verification UI for the user with the namespace and id values,
  // and a callback which is triggered when the user finishes the flow.
  OTPGateway(
    namespaceVal,
    idVal,
    function(nm, id) {
      console.log("finished", nm, id);

      // 3. Post the namespace and id to your server that will make the
      // status request to the gateway and on success, update the user's
      // address in your records as it's now verified.
    },
    function() {
      console.log("cancelled");
    }
  );
</script>

Licensed under the MIT license.
