mholt/caddy-ratelimit

Caddy HTTP Rate Limit Module

This module implements both internal and distributed HTTP rate limiting. Requests can be rejected after a specified rate limit is hit.

[!NOTE] This is not an official repository of the Caddy Web Server organization.

Features

• Multiple rate limit zones
  • Static or dynamic
  • Can be based on request host, header, remote IP, client IP, etc.
• Sliding window algorithm
• Scalable ring buffer implementation
  • Buffer pooling
  • Goroutines: 1 (to clean up old buffers)
  • Memory O(Kn) where:
    • K = events allowed in window (constant, configurable)
    • n = number of rate limits allocated in zone (configured by zone key; constant or dynamic)
• RL state persisted through config reloads
• Automatically sets Retry-After header
• Optional jitter for retry times
• Configurable memory management
• Distributed rate limiting across a cluster
• Caddyfile support

PLANNED:

• Smoothed estimates of distributed rate limiting
• RL state persisted in storage for resuming after restarts
• Admin API endpoints to inspect or modify rate limits

Building

To build Caddy with this module, use xcaddy:

$ xcaddy build --with github.com/mholt/caddy-ratelimit

Overview

The rate_limit HTTP handler module lets you define rate limit zones, which have a unique name of your choosing. A rate limit zone is 1:1 with a rate limit (i.e. events per duration).

A zone also has a key, which is different from its name. Keys associate 1:1 with rate limiters, implemented as ring buffers; i.e. a new key implies allocating a new ring buffer. Keys can be static (no placeholders; same for every request), in which case only one rate limiter will be allocated for the whole zone. Or, keys can contain placeholders which can be different for every request, in which case a zone may contain numerous rate limiters depending on the result of expanding the key.

A zone is synonymous with a rate limit, being a number of events per duration. Both window and max_events are required configuration for a zone. For example: 100 events every 1 minute. Because this module uses a sliding window algorithm, it works by looking back <window> duration and seeing if <max_events> events have already happened in that timeframe. If so, an internal HTTP 429 error is generated and returned, invoking error routes which you have defined (if any). Otherwise, a reservation is made and the event is allowed through.

Each zone may optionally filter the requests it applies to by specifying request matchers.

Unlike nginx's rate limit module, this one does not require you to set a memory bound. Instead, rate limiters are scanned every so often and expired ones are deleted so their memory can be recovered by the garbage collector: Caddy does not drop rate limiters on the floor and forget events like nginx does.

Distributed rate limiting

With a little bit more CPU, I/O, and a teensy bit more memory overhead, this module distributes its rate limit state across a cluster. A cluster is simply defined as other rate limit modules that are configured to use the same storage.

Distributed RL works by periodically writing its internal RL state to storage, while also periodically reading other instances' RL state from storage, then accounting for their states when making allowance decisions. In order for this to work, all instances in the cluster must have the exact same RL zone configurations.

This synchronization algorithm is inherently approximate, but also eventually consistent (and is similar to what other enterprise-only rate limiters do). Its performance depends heavily on parameter tuning (e.g. how often to read and write), configured rate limit windows and event maximums, and performance characteristics of the underlying storage implementation. (It will be fairly heavy on reads, but writes will be lighter, even if more frequent.)

Syntax

This is an HTTP handler module, so it can be used wherever http.handlers modules are accepted.

JSON config

{
	"handler": "rate_limit",
	"rate_limits": {
		"<name>": {
			"match": [],
			"key": "",
			"window": "",
			"max_events": 0,
			"ipv4_prefix": 0,
			"ipv6_prefix": 0
		}
	},
	"jitter": 0.0,
	"sweep_interval": "",
	"log_key": false,
	"disable_metrics": false,
	"storage": {},
	"distributed": {
		"write_interval": "",
		"read_interval": "",
		"purge_age": ""
	},
}

All fields are optional, but to be useful, you'll need to define at least one zone, and a zone requires window and max_events to be set. Keys can be static (no placeholders) or dynamic (with placeholders). Matchers can be used to filter requests that apply to a zone. Replace <name> with your RL zone's name.

The ipv4_prefix and ipv6_prefix fields allow grouping rate limit keys by network subnet when the key resolves to an IP address. For example, setting ipv6_prefix to 64 will mask all IPv6 addresses to their /64 network prefix, so all addresses within the same /64 share a single rate limit bucket. This is useful for preventing abuse from clients cycling through many addresses within an IPv6 prefix. Each address family is configured independently; when a prefix is not set (or 0), addresses of that family are treated individually as usual.

To enable distributed RL, set distributed to a non-null object. The default read and write intervals are 5s, but you should tune these for your individual deployments.

To log the key when a rate limit is hit, set log_key to true.

To disable Prometheus metrics for this handler even when Caddy global metrics are enabled, set disable_metrics to true. This is useful if you want to use Caddy's metrics but are not interested in the rate limit module's metrics and want to avoid unnecessary Prometheus storage usage.

Storage customizes the storage module that is used. Like normal Caddy convention, all instances with the same storage configuration are considered to be part of a cluster.

Jitter is an optional percentage that adds random variance to the Retry-After time to avoid stampeding herds.

Sweep interval configures how often to scan for expired rate limiters. The default is 1m.

Caddyfile config

By default, the rate_limit directive is ordered before basic_auth in the Caddyfile. This simplifies configuration and removes the need for manual ordering in most cases. However, if this default order does not suit your needs, you can still change the order using the order global directive. For example:

{
	order rate_limit after basic_auth
}

If the rate_limit directive is used within a route block, it will follow the order specified by the route block, allowing for more flexible and complex configurations. For example:

route {
	# Uncritical resource without rate limit
	respond /ping "pong"

	# Apply rate limit
	rate_limit {
		...
	}

	# Critical resources after rate limiting
	...
}

Here is the syntax. See the JSON config section above for explanations about each property:

rate_limit {
	zone <name> {
		match {
			<matchers>
		}
		key         <string>
		window      <duration>
		events      <max_events>
		ipv4_prefix <bits>
		ipv6_prefix <bits>
	}
	distributed {
		read_interval  <duration>
		write_interval <duration>
		purge_age <duration>
	}
	log_key
	disable_metrics
	storage <module...>
	jitter  <percent>
	sweep_interval <duration>
}

Like with the JSON config, all subdirectives are optional and have sensible defaults (but you will obviously want to specify at least one zone).

Multiple zones can be defined. Distributed RL can be enabled just by specifying distributed if you want to use its default settings.

Examples

We'll show an equivalent JSON and Caddyfile example that defines two rate limit zones: static_example and dynamic_example.

In the static_example zone, there is precisely one ring buffer allocated because the key is static (no placeholders), and we also demonstrate defining a matcher set to select which requests the rate limit applies to. Only 100 GET requests will be allowed through every minute, across all clients.

In the dynamic_example zone, the key is dynamic (has a placeholder), and in this case we're using the client's IP address ({http.request.remote.host}). We allow only 2 requests per client IP in the last 5 seconds from any given time.

We also enable distributed rate limiting. By deploying this config to two or more instances sharing the same storage module (which we did not define here, so Caddy's global storage config will be used), they will act approximately as one instance when making rate limiting decisions.

JSON example

{
	"apps": {
		"http": {
			"servers": {
				"demo": {
					"listen": [":80"],
					"routes": [
						{
							"handle": [
								{
									"handler": "rate_limit",
									"rate_limits": {
										"static_example": {
											"match": [
												{"method": ["GET"]}
											],
											"key": "static",
											"window": "1m",
											"max_events": 100
										},
										"dynamic_example": {
											"key": "{http.request.remote.host}",
											"window": "5s",
											"max_events": 2
										}
									},
									"distributed": {},
									"log_key": true
								},
								{
									"handler": "static_response",
									"body": "I'm behind the rate limiter!"
								}
							]
						}
					]
				}
			}
		}
	}
}

Caddyfile example

:80

rate_limit {
	distributed
	zone static_example {
		match {
			method GET
		}
		key    static
		events 100
		window 1m
	}
	zone dynamic_example {
		key    {remote_host}
		events 2
		window 5s
	}
	log_key
}

respond "I'm behind the rate limiter!"

Network prefix rate limiting

When rate limiting by client IP, an attacker with access to an IPv6 prefix (commonly a /64) can cycle through many addresses to bypass per-IP rate limits. The ipv6_prefix option solves this by grouping all addresses within the same network into a single rate limit bucket.

In this example, all IPv6 clients within the same /64 network share one rate limit bucket, while each IPv4 client is rate limited individually:

JSON

{
	"handler": "rate_limit",
	"rate_limits": {
		"per_network": {
			"key": "{http.request.remote.host}",
			"window": "1m",
			"max_events": 100,
			"ipv6_prefix": 64
		}
	}
}

Caddyfile

rate_limit {
	zone per_network {
		key         {remote_host}
		events      100
		window      1m
		ipv6_prefix 64
	}
}
