RmlUi - The HTML/CSS User Interface Library Evolved

RmlUi - now with added boosters taking control of the rocket, targeting your games and applications.

---

RmlUi is the C++ user interface package based on the HTML and CSS standards, designed as a complete solution for any project's interface needs. It is a fork of the libRocket project, introducing new features, bug fixes, and performance improvements.

RmlUi aims at being a light-weight and performant library with its own layout engine and few dependencies. In essence, RmlUi takes your HTML/CSS-like source files and turns them into vertices, indices and draw commands, and then you bring your own renderer to draw them. And of course there is full access to the element hierarchy/DOM, event handling, and all the interactivity and customizability you would expect. All of this directly from C++, or optionally from scripting languages using plugins. The core library compiles down to fractions of the size it takes to integrate a fully fledged web browser.

RmlUi is based around the XHTML1 and CSS2 standards while integrating features from HTML5 and CSS3, and extends them with features suited towards real-time applications. Take a look at the conformance and enhancements sections below for details.

Documentation is located at https://mikke89.github.io/RmlUiDoc/

Features

• Cross-platform architecture: Windows, Linux, macOS, Android, iOS, Switch, and more.
• Dynamic layout system.
• Full animation and transform support.
• Efficient application-wide styling, with a custom-built templating engine.
• Fully featured control set: buttons, sliders, drop-downs, and more.
• Runtime visual debugging suite.

Extensible

• Abstracted interfaces for plugging in to any game engine.
• Decorator engine allowing custom application-specific effects that can be applied to any element.
• Generic event system that binds seamlessly into existing projects.
• Easily integrated and extensible with the Lua scripting plugin.

Controllable

• The user controls their own update loop, calling into RmlUi as desired.
• The library strictly runs as a result of calls to its API, never in the background.
• Input handling and rendering is performed by the user.
• The library generates vertices, indices, and textures for the user to render how they like.
• File handling and the font engine can optionally be fully replaced by the user.

Conformance

RmlUi aims to support the most common and familiar features from HTML and CSS, while keeping the library light and performant. We do not aim to be fully compliant with CSS or HTML, in particular when it conflicts with lightness and performance. Users are generally expected to author documents specifically for RmlUi, but any experience and skills from web design should be transferable.

RmlUi supports most of CSS2 with some CSS3 features such as

• Animations and transitions
• Transforms (with full interpolation support)
• Flexbox layout
• Media queries
• Border radius
• Box shadows and mask images
• Gradients (linear, radial, and conic) as decorators
• Filters and backdrop filters (with all CSS filter functions)

and many of the common HTML elements including <input>, <textarea>, and <select>.

For details, see

• RCSS Property index for all supported properties and differences from CSS.
• RML Element index for all supported elements.

Enhancements

RmlUi adds features and enhancements over CSS and HTML where it makes sense, most notably the following.

• Data binding (model-view-controller). Synchronization between application data and user interface.
• Decorators. Full control over the styling of all elements.
• Sprite sheets. Define and use sprites with easy high DPI support.
• Templates. Making windows look consistent.
• Localization. Translate any text in the document.
• Spatial navigation. Suitable for controllers.

Dependencies

• FreeType. However, it can be fully replaced by a custom font engine.
• The standard library.

In addition, a C++17 compatible compiler is required.

Building RmlUi

CMake

RmlUi can be built using CMake and your favorite compiler, see the building documentation for details and all the options. Windows binaries are also available for the latest release.

vcpkg

RmlUi can also be fetched from a dependency manager such as vcpkg.

vcpkg install rmlui

That's it! See below for details on integrating RmlUi.

To build RmlUi with the included samples we can use git and CMake together with vcpkg to handle dependencies.

vcpkg install freetype glfw3
git clone https://github.com/mikke89/RmlUi.git
cd RmlUi
cmake -B Build -S . --preset samples -DRMLUI_BACKEND=GLFW_GL3 -DCMAKE_TOOLCHAIN_FILE="<path-to-vcpkg>/scripts/buildsystems/vcpkg.cmake"
cmake --build Build

Make sure to replace <path-to-vcpkg> as appropriate. This example uses the GLFW_GL3 backend, other backends are available as shown below. When this completes, feel free to test the freshly built samples, such as the invaders sample (rmlui_sample_invaders target), and enjoy! The executables should be located somewhere in the Build directory.

To make all the samples available, you can additionally install lua lunasvg rlottie harfbuzz and pass --preset samples-all during CMake configuration.

Integrating RmlUi

Here are the general steps to integrate the library into a C++ application, have a look at the integration documentation for details.

1. Build RmlUi as above or fetch the binaries, and link it up to your application.
2. Implement the abstract render interface, or fetch one of the backends listed below.
3. Initialize RmlUi with the interfaces, create a context, provide font files, and load a document.
4. Call into the context's update and render methods in a loop, and submit input events.
5. Compile and run!

Several samples demonstrate everything from basic integration to more complex use of the library, feel free to have a look for inspiration.

RmlUi Backends

To ease the integration of RmlUi, the library includes many backends adding support for common renderers and platforms. The following terms are used here:

• Renderer: Implements the render interface for a given rendering API, and provides initialization code when necessary.
• Platform: Implements the system interface for a given platform (operating system or window library), and adds procedures for providing input to RmlUi contexts.
• Backend: Combines a renderer and a platform for a complete windowing framework sample, implementing the basic Backend interface.

The provided renderers and platforms are intended to be usable as-is by client projects without modifications, thereby circumventing the need to write custom interfaces. We encourage users to only make changes here when they are useful to all users, and then contribute back to the project. However, if they do not meet your needs it is also possible to copy them into your project for modifications. Feedback is welcome to find the proper abstraction level. The provided system and render interfaces are designed such that they can be derived from and further customized by the backend or end user.

The provided backends on the other hand are not intended to be used directly by client projects, but rather copied and modified as needed. They are intentionally light-weight and implement just enough functionality to make the included samples run, while being simple to understand and build upon by users. See the manual for backend integration details.

Renderers

* Reference implementation

Basic rendering: Render geometry with colors, textures, and rectangular clipping (scissoring). Sufficient for basic 2D layouts.
Transforms: Enables the transform and perspective properties to take effect.
Clip masks: Enables proper clipping of transformed elements, elements with border-radius.
Filters: Support for the filter and backdrop-filter properties with all filter functions, such as blur and drop-shadow.
Shaders: Support for all built-in decorators that require shaders, such as linear-gradient and radial-gradient. Other advanced rendering functions are also implemented, including render-to-texture and masking support for properties such as box-shadow and mask-image.
Built-in image support: This only shows the supported formats built-in to the renderer, users are encouraged to derive from and extend the render interface to add support for their desired image formats.

Platforms

Basic windowing: Open windows, react to resize events, submit inputs to the RmlUi context.
Clipboard: Read from and write to the system clipboard.
High DPI: Scale the dp-ratio of RmlUi contexts based on the monitor's DPI settings. React to DPI-changes, either because of changed settings or when moving the window to another monitor.
Touch: Process touch events, enable dragging and inertial scrolling with touch movement.

Backends

¹ SDL backends extend their respective renderers to provide image support based on SDL_image.
² Supports Emscripten compilation target.

When building the samples, the backend can be selected by setting the CMake option RMLUI_BACKEND to a combination of a platform and renderer, according to the above table.

Example document

This example demonstrates a basic document with data bindings, which is loaded and displayed using the C++ code below.

Document

hello_world.rml

<rml>
<head>
    <title>Hello world</title>
    <link type="text/rcss" href="rml.rcss"/>
    <link type="text/rcss" href="window.rcss"/>
</head>
<body data-model="animals">
    <h1>RmlUi</h1>
    <p>Hello <span id="world">world</span>!</p>
    <p data-if="show_text">The quick brown fox jumps over the lazy {{animal}}.</p>
    <input type="text" data-value="animal"/>
</body>
</rml>

The {{animal}} text and the data-if, data-value attributes represent data bindings and will synchronize with the application data.

Style sheet

window.rcss

body {
    font-family: LatoLatin;
    font-size: 18px;
    color: #02475e;
    background: #fefecc;
    text-align: center;
    padding: 2em 1em;
    position: absolute;
    border: 2px #ccc;
    width: 500px;
    height: 200px;
    margin: auto;
}

h1 {
    color: #f6470a;
    font-size: 1.5em;
    font-weight: bold;
    margin-bottom: 0.7em;
}

p {
    margin: 0.7em 0;
}

input.text {
    background-color: #fff;
    color: #555;
    border: 2px #999;
    padding: 5px;
    tab-index: auto;
    cursor: text;
    box-sizing: border-box;
    width: 200px;
    font-size: 0.9em;
}

RmlUi defines no styles internally, thus the input element is styled here, and rml.rcss is included for proper layout of common tags.

C++ Initialization and loop

main.cpp

#include <RmlUi/Core.h>

class MyRenderInterface : public Rml::RenderInterface
{
    // RmlUi sends vertices, indices and draw commands through this interface for your
    // application to render how you'd like.
    /* ... */
};

struct ApplicationData {
    bool show_text = true;
    Rml::String animal = "dog";
} my_data;

int main(int argc, char** argv)
{
    // Initialize the window and graphics API being used, along with your game or application.

    /* ... */

    MyRenderInterface render_interface;

    // Install the custom interfaces.
    Rml::SetRenderInterface(&render_interface);

    // Now we can initialize RmlUi.
    Rml::Initialise();

    // Create a context to display documents within.
    Rml::Context* context =
        Rml::CreateContext("main", Rml::Vector2i(window_width, window_height));

    // Tell RmlUi to load the given fonts.
    Rml::LoadFontFace("LatoLatin-Regular.ttf");
    // Fonts can be registered as fallback fonts, as in this case to display emojis.
    Rml::LoadFontFace("NotoEmoji-Regular.ttf", true);

    // Set up data bindings to synchronize application data.
    if (Rml::DataModelConstructor constructor = context->CreateDataModel("animals"))
    {
        constructor.Bind("show_text", &my_data.show_text);
        constructor.Bind("animal", &my_data.animal);
    }

    // Now we are ready to load our document.
    Rml::ElementDocument* document = context->LoadDocument("hello_world.rml");
    document->Show();

    // Replace and style some text in the loaded document.
    Rml::Element* element = document->GetElementById("world");
    element->SetInnerRML(reinterpret_cast<const char*>(u8"🌍"));
    element->SetProperty("font-size", "1.5em");

    bool exit_application = false;
    while (!exit_application)
    {
        // We assume here that we have some way of updating and retrieving inputs internally.
        if (my_input->KeyPressed(KEY_ESC))
            exit_application = true;

        // Submit input events such as MouseMove and key events (not shown) to the context.
        if (my_input->MouseMoved())
            context->ProcessMouseMove(mouse_pos.x, mouse_pos.y, 0);

        // Update the context to reflect any changes resulting from input events, animations,
        // modified and added elements, or changed data in data bindings.
        context->Update();

        // Prepare the application for rendering, such as by clearing the window. This calls
        // into the RmlUi backend interface, replace with your own procedures as appropriate.
        Backend::BeginFrame();

        // Render the user interface. All geometry and other rendering commands are now
        // submitted through the render interface.
        context->Render();

        // Present the rendered content, such as by swapping the swapchain. This calls into
        // the RmlUi backend interface, replace with your own procedures as appropriate.
        Backend::PresentFrame();
    }

    Rml::Shutdown();

    return 0;
}

Rendered output

Users can now edit the text field to change the animal. The data bindings ensure that both the document text and the application string my_data.animal are automatically modified accordingly.

Gallery

Game menu

RmlUi 'invaders' sample

The Thing: Remastered

The Thing: Remastered by Nightdive Studios. Restoration of the cult-classic 2002 third-person survival horror shooter game inspired by the 1982 film, The Thing. User interface made with RmlUi.

Alchemist

Alchemist by Cfx.re (Rockstar Games). Tool to convert assets from GTAV Legacy to GTAV Enhanced.

Gearmulator

Gearmulator by The Usual Suspects. Family of emulators for classic VA synths of the late 90s/00s with the Motorola 56300 family DSPs.

WOTInspector

WOTInspector. Tool for World of Tanks players helping to learn and understand game mechanics. User interface made with RmlUi.

ROSE Online

ROSE Online. A free-to-play 3D fantasy MMORPG. User interface made with RmlUi.

Character selection.

World map with custom map rendering and interaction.

https://github.com/user-attachments/assets/a8ce9ece-8b63-45dd-84ba-df9c4187ad88

Crafting with animations and drag & drop.

https://github.com/user-attachments/assets/c336e19b-3448-4d92-ad4a-72cf7ec7185c

Killing Time: Resurrected

Killing Time: Resurrected by Nightdive Studios. Remastered version of the classic shooter game. User interface made with RmlUi.

Unvanquished

Unvanquished. A first-person shooter game with real-time strategy elements. Menus and HUD in RmlUi.

vkQuake + RmlUi

vkQuake + RmlUi. A vkQuake fork that replaces Quake's menu and HUD systems with RmlUi. [teaser trailer]

alt:V installer

alt:V installer. A multiplayer client for GTA V.

TruckersMP

TruckersMP. A multiplayer mod for truck simulators. Chat box and player panel in RmlUi.

Installer software by @xland

RmlUi 'data_binding' sample

Simple game demonstrating the use of data bindings.

RmlUi 'effects' sample

Applying advanced filters.

Effects sample video

RmlUi collage of advanced effects

RmlUi 'demo' sample

Form controls from the 'demo' sample.

Sandbox from the 'demo' sample, try it yourself!

Transitions on mouse hover (entirely in RCSS).

Animated transforms (entirely in RCSS).

RmlUi flexbox layout

RmlUi visual testing framework

For built-in automated layout tests.

RmlUi 'animation' sample

Animation sample

Transitions and transforms on a game menu

Game main menu

Camera movement in a game menu

Transforms applied to game menu

RmlUi 'lottie' sample

Vector animations with the Lottie plugin.

RmlUi 'svg' sample

Vector images with the SVG plugin.

See more

Additional screenshots from thirdparty projects can be found in:

• Gallery discussion thread.
• Thirdparty projects discussion thread and links therein.

License

RmlUi license

RmlUi is published under the MIT license, see LICENSE.txt.

Third-party licenses

The library includes third-party source code and assets with their own licenses, as detailed below.

Third-party source code included in RmlUi Core

See Include/RmlUi/Core/Containers/LICENSE.txt - all MIT licensed.

Third-party font assets included in RmlUi Debugger

See Source/Debugger/LICENSE.txt - SIL Open Font License.

Additional sample assets (in Samples/)

See

• Samples/assets/LICENSE.txt
• Samples/basic/bitmap_font/data/LICENSE.txt
• Samples/basic/harfbuzz/data/LICENSE.txt
• Samples/basic/lottie/data/LICENSE.txt
• Samples/basic/svg/data/LICENSE.txt

Library included with the Vulkan backend (in Backends/RmlUi_Vulkan/)

See Backends/RmlUi_Vulkan/LICENSE.txt - MIT license.

Library included with the DirectX 12 backend (in Backends/RmlUi_DirectX/)

See Backends/RmlUi_DirectX/LICENSE.txt - MIT license.

Library included with the SDL GPU backend (in Backends/RmlUi_SDL_GPU/)

See Backends/RmlUi_SDL_GPU/SDL_shadercross/LICENSE.txt - Zlib license.

Libraries included with the test suite (in Tests/Dependencies/)

See Tests/Dependencies/LICENSE.txt.

Additional test suite assets (in Tests/Data/VisualTests/)

See Tests/Data/VisualTests/LICENSE.txt.
