MobSF/RP4MobSF

RP4MobSF

a nginx reverse proxy with ssl and auth for MobSF

This docker image will let you run a ssl reverse proxy with basic authentication in front of your mobsf

This image use nginx-extras to provide extra features

1. to build the image

   • if you are behing a proxy

     • docker build --no-cache --build-arg http_proxy=${http_proxy} --build-arg https_proxy=${https_proxy} -t rp4mobsf:latest .

   • if not :

     • docker build --no-cache -t rp4mobsf:latest .

2. you have a run.sh you can customize for your need :

export CONF_DIR='/home/debian/nginx_mobsfv2/conf/conf.d'

export PKI_DIR='/home/debian/nginx_mobsfv2/conf/pki'

export AUTH_DIR='/home/debian/nginx_mobsfv2/conf/auth'

docker run -d
-p 80:80 -p 443:443
-e 'DH_SIZE=512'
-e 'FORWARD_HOST=172.17.0.2'
-e 'FORWARD_PORT=8000'
-v $CONF_DIR:/etc/nginx/conf.d:rw
-v $PKI_DIR:/etc/nginx/pki:rw
-v $AUTH_DIR:/etc/nginx/auth:ro
--name rp4mobsf
rp4mobsf:latest

3. Parameters:

   • CONF_DIR is the path to your conf directory which contain configuration
   • PKI_DIR is the path to your directory containing the certificate
   • AUTH_DIR is the path to your directory containing your auth.htpasswd file (user/password file)
   • FORWARD_HOST is the @IP or FQDN or your MobSF server
   • FORWARD_PORT is the port used to access MOBSF web interface

4. Default user :

   • Default user is foo password bar

5. Managing password

• if you want to change or add user, you must use htpasswd binary to generate password and put the poassword in the auth.htppasswd file located in your conf directory

  • syntax will be :

    • htpasswd -b ./conf/auth.htpasswd foo bar (for user foo with password bar)

  • to install and use htpasswd on your system refer too :

    • https://httpd.apache.org/docs/current/programs/htpasswd.html

6. Certificates

• if you already have certificates put it in conf/pki/ ($EXT_DIR/pki/)
• if you don't have the image will create autosigned certificates

7. Custom

• nginx will not send the nginx version in header
• nginx will send a custom name not nginx in header
  • to change the value :
    • edit basic .conf and modify : more_set_headers "Server: MobSF RP";

8. Variables

• if you want upload a file bigger than 300M you must modify client_max_body_size 300M; in auth.conf
• by default you have a 10 minutes cache so if you go to recent scan just after doing an analysis, you will not see it.

This image is based on: MarvAmBass/docker-nginx-ssl-secure
