ory/kratos-selfservice-ui-node

Ory Kratos NodeJS / ExpressJS User Interface Reference Implementation

This repository contains a reference implementation for Ory Kratos' in NodeJS / ExpressJS / Handlebars / NextJS. It implements all Ory Kratos flows (login, registration, account settings, account recovery, account verification).

If you only want to add authentication to your app, and not customize the login, registration, account recovery, ... screens, please check out the Ory Kratos Quickstart.

Configuration

Below is a list of environment variables required by the Express.js service to function properly.

In a local development run of the service using npm run start, some of these values will be set by nodemon and is configured by the nodemon.json file.

When using this UI with an Ory Network project, you can use ORY_SDK_URL instead of KRATOS_PUBLIC_URL and HYDRA_ADMIN_URL.

Ory Identities requires the following variables to be set:

• ORY_SDK_URL or KRATOS_PUBLIC_URL (required): The URL where ORY Kratos's Public API is located at. If this app and ORY Kratos are running in the same private network, this should be the private network address (e.g. kratos-public.svc.cluster.local).
• KRATOS_BROWSER_URL (optional) The browser accessible URL where ORY Kratos's public API is located, only needed if it differs from KRATOS_PUBLIC_URL
• KRATOS_ADMIN_URL (optional) The URL where Ory Kratos' Admin API is located at (e.g. http://kratos:4434).

Ory OAuth2 requires more setup to get CSRF cookies on the /consent endpoint.

• ORY_SDK_URL or HYDRA_ADMIN_URL (optional): The URL where Ory Hydra's Admin API is located at. If this app and Ory Hydra are running in the same private network, this should be the private network address (e.g. hydra-admin.svc.cluster.local)

• COOKIE_SECRET (required): Required for signing cookies. Must be a string with at least 8 alphanumerical characters.

• CSRF_COOKIE_NAME (required): Change the cookie name to match your domain using the __HOST-example.com-x-csrf-token format.

• CSRF_COOKIE_SECRET (optional): Required for the Consent route to set a CSRF cookie with a hashed value. The value must be a string with at least 8 alphanumerical characters.

• REMEMBER_CONSENT_SESSION_FOR_SECONDS (optional): Sets the remember_for value of the accept consent request in seconds. The default is 3600 seconds.

• ORY_ADMIN_API_TOKEN (optional): When using with an Ory Network project, you should add the ORY_ADMIN_API_TOKEN for OAuth2 Consent flows.

• DANGEROUSLY_DISABLE_SECURE_CSRF_COOKIES (optional) This environment variables should only be used in local development when you do not have HTTPS setup. This sets the CSRF cookies to secure: false, required for running locally. When using this setting, you must also set CSRF_COOKIE_NAME to a name without the __Host- prefix.

• TRUSTED_CLIENT_IDS (optional): A list of trusted client ids. They can be set to skip the consent screen.

• SESSION_EXTRA_TRAITS_ID_TOKEN (optional): Comma-separated list of Kratos identity trait names to propagate verbatim into session.id_token during the OAuth2 consent flow. Any trait present on identity.traits under one of the listed names is copied to the ID token; missing traits are skipped. Useful when downstream apps rely on identity attributes that aren't part of the built-in email / profile claim mapping (e.g. groups, department, tenant_id). Example: SESSION_EXTRA_TRAITS_ID_TOKEN=groups,department.

• SESSION_EXTRA_TRAITS_ACCESS_TOKEN (optional): Same as above but for session.access_token. Set both if the trait needs to be readable from both tokens.

  Note: unlike the built-in email / profile claims (which are only added when the OIDC client requests the corresponding scope), traits listed in these env vars are propagated unconditionally into every issued token, regardless of which scopes the client asked for. Only enable this when the trait should always be present and its exposure to any OIDC client of this UI is acceptable.

Getting TLS working:

• TLS_CERT_PATH (optional): Path to certificate file. Should be set up together with TLS_KEY_PATH to enable HTTPS.
• TLS_KEY_PATH (optional): Path to key file Should be set up together with TLS_CERT_PATH to enable HTTPS.

This is the easiest mode as it requires no additional set up. This app runs on port :4455 and ORY Kratos KRATOS_PUBLIC_URL URL.

This mode relies on the browser's ability to send cookies regardless of the port. Cookies set for 127.0.0.1:4433 will thus also be sent when requesting 127.0.0.1:4455. For environments where applications run on separate subdomains, check out Multi-Domain Cookies

To authenticate incoming requests, this app uses ORY Kratos' whoami API to check whether the session is valid or not.

Base Path

There are two ways of serving this application under a base path:

1. Let Express.js handle the routing by setting the BASE_PATH environment variable to the sub-path, e.g. /myapp.
2. Use a reverse proxy or API gateway to strip the path prefix.

The second approach is not always possible, especially when running the application on a serverless environment. In this case, the first approach is recommended.

Development

To run this app with dummy data and no real connection to ORY Kratos, use:

NODE_ENV=stub npm start

If you would like to also generate fake data for the id_token, please set the environment varialbe export CONFORMITY_FAKE_CLAIMS=1

Test with ORY Kratos

The easiest way to test this app with a local installation of ORY Kratos is to have the ORY Kratos Quickstart running. This is what that would look like:

# start the quickstart using docker compose as explained in the tutorial: https://www.ory.com/kratos/docs/quickstart/
export KRATOS_PUBLIC_URL=http://127.0.0.1:4433/
export PORT=4455

# In ORY Kratos run the quickstart:
#
#   make quickstart-dev
#
# Next you need to kill the docker container that runs this app in order to free the ports:
#
#   docker kill kratos_kratos-selfservice-ui-node_1

npm start

Update TypeScript SDK

If you've made changes to the ORY Kratos API you may want to manually generate the TypeScript SDK in order for URLs and payloads to work as expected. It is expected that you start this guide from this project's root, wherever you checked it out. You also need to have the openapi-generator installed.

# Set path to kratos:
export KRATOS_DIR=/path/to/kratos
make build-sdk

Building the Docker Image

# Set path to kratos:
export KRATOS_DIR=/path/to/kratos
make build-sdk-docker

Clean up

make clean-sdk
