seaweedfs/seaweedfs-operator

SeaweedFS Operator

This Kubernetes Operator is made to easily deploy SeaweedFS onto your Kubernetes cluster.

The operator manages the complete SeaweedFS infrastructure on Kubernetes, including Master servers, Volume servers, and Filer services with S3-compatible API and embedded IAM (Identity and Access Management). This provides a scalable, resilient distributed file system with built-in authentication.

The difference to seaweedfs-csi-driver is that the infrastructure (SeaweedFS) itself runs on Kubernetes as well (Master, Filer, Volume-Servers) and can as such easily scale with it as you need. It is also by far more resilent to failures then a simple systemD service in regards to handling crashing services or accidental deletes.

By using make deploy it will deploy a Resource of type 'Seaweed' onto your current kubectl $KUBECONFIG target (the operator itself) which by default will do nothing unless you configurate it (see examples in config/samples/).

Goals:

• Automatically deploy and manage a SeaweedFS cluster
• Ability to be managed by other Operators
• Compatibility with seaweedfs-csi-driver (deploy it via the SeaweedCSIDriver CR — see CSI_SUPPORT.md)
• Auto rolling upgrade and restart
• Ingress for volume server, filer and S3, to support HDFS, REST filer, S3 API and cross-cluster replication
• IAM (Identity and Access Management) service support for S3 API authentication and authorization
• Support all major cloud Kubernetes: AWS, Google, Azure
• Scheduled backup and restore: filer metadata snapshots + continuous data mirror to S3, Google Cloud Storage, Azure, Backblaze B2, or a PVC (see BACKUP_SUPPORT.md)
• Put warm data to cloud storage tier: S3, Google Cloud Storage , Azure
• Grafana dashboard

Installation

Helm

helm repo add seaweedfs-operator https://seaweedfs.github.io/seaweedfs-operator/
helm template seaweedfs-operator seaweedfs-operator/seaweedfs-operator

Note: For versions prior to 0.1.2, the legacy repository URL https://seaweedfs.github.io/seaweedfs-operator/helm can still be used, but new releases will only be published to the main repository URL above.

Upgrading from chart versions <= 0.1.14

Starting in chart version 0.1.15, the seaweeds.seaweed.seaweedfs.com CRD is shipped as a templated resource instead of living in crds/. This lets helm upgrade actually update it — the crds/ directory is install-only in Helm 3.

If you already have the chart installed, run these once before your next helm upgrade so Helm can take over the existing CRD. Look up your release name and namespace first — they must match exactly, or Helm will still refuse to adopt the CRD:

helm list -A | grep seaweedfs-operator
# Replace the two values below with the NAME and NAMESPACE you see above.
RELEASE=<release-name>
NAMESPACE=<release-namespace>
kubectl label crd seaweeds.seaweed.seaweedfs.com app.kubernetes.io/managed-by=Helm --overwrite
kubectl annotate crd seaweeds.seaweed.seaweedfs.com \
  meta.helm.sh/release-name=$RELEASE \
  meta.helm.sh/release-namespace=$NAMESPACE --overwrite

The CRD is annotated with helm.sh/resource-policy: keep, so helm uninstall will leave it and your Seaweed resources in place.

If the CRD is managed outside of this chart (e.g., installed cluster-wide via GitOps), set --set crds.create=false on install/upgrade so Helm does not try to own it. Note: helm --skip-crds has no effect here because the CRD lives in templates/, not crds/.

FluxCD

Add the following files to a new directory called seaweedfs-operator under your FluxCD GitRepository (publishing) directory.

kustomization.yaml

apiVersion: kustomize.config.k8s.io/v1beta1
kind: Kustomization
resources:
  - seaweedfs-operator-namespace.yaml
  - seaweedfs-operator-helmrepository.yaml
  - seaweedfs-operator-helmrelease.yaml

seaweedfs-operator-namespace.yaml

apiVersion: v1
kind: Namespace
metadata:
  name: seaweedfs-operator

seaweedfs-operator-helmrepository.yaml

apiVersion: source.toolkit.fluxcd.io/v1
kind: HelmRepository
metadata:
  name: seaweedfs-operator
  namespace: seaweedfs-operator
spec:
  interval: 1h
  url: https://seaweedfs.github.io/seaweedfs-operator/

seaweedfs-operator-helmrelease.yaml

apiVersion: helm.toolkit.fluxcd.io/v2
kind: HelmRelease
metadata:
  name: seaweedfs-operator
  namespace: seaweedfs-operator
spec:
  interval: 1h
  chart:
    spec:
      chart: seaweedfs-operator
      sourceRef:
        kind: HelmRepository
        name: seaweedfs-operator
        namespace: seaweedfs-operator

The webhook is enabled by default. Its server certificate is generated by a pre-install,pre-upgrade Helm hook job, so the seaweedfs-operator-webhook-server-cert secret exists before the operator deployment starts — no manual two-step enable is needed.

Manual

This operator uses kustomize for deployment. Please install kustomize if you do not have it.

By default, the defaulting and validation webhooks are disabled, so make deploy works on any cluster without cert-manager. We strongly recommend enabling the webhooks for production use.

First clone the repository:

git clone https://github.com/seaweedfs/seaweedfs-operator --depth=1

To deploy the operator with webhooks enabled, make sure you have installed the cert-manager(Installation docs: https://cert-manager.io/docs/installation/) in your cluster, then follow the instructions in the config/default/kustomization.yaml file to uncomment all the [WEBHOOK] and [CERTMANAGER] sections (including the one in config/crd/kustomization.yaml). Uncommenting those sections also flips ENABLE_WEBHOOKS to "true" for you via config/default/manager_webhook_patch.yaml, so no separate edit of config/manager/manager.yaml is needed.

Manager image must be locally built and published into a registry accessible from your k8s cluster:

export IMG=<registry/image:tag>

# Build and push for amd64
export TARGETARCH=amd64

# Optional if you want to change TARGETOS
# export TARGETOS=linux

make docker-build

# Build and push for arm64
export TARGETARCH=arm64
make docker-build

Afterwards fire up to install CRDs:

make install

Then run the command to deploy the operator into your cluster using Kustomize or Helm:

# if using Kustomize
make deploy
# if using Helm
helm install seaweedfs-operator ./deploy/helm

Verify it was correctly deployed:

kubectl get pods --all-namespaces

Which may return:

NAMESPACE                   NAME                                                     READY   STATUS    RESTARTS   AGE
kube-system                 coredns-f9fd979d6-68p4c                                  1/1     Running   0          34m
kube-system                 coredns-f9fd979d6-x992t                                  1/1     Running   0          34m
kube-system                 etcd-kind-control-plane                                  1/1     Running   0          34m
kube-system                 kindnet-rp7wr                                            1/1     Running   0          34m
kube-system                 kube-apiserver-kind-control-plane                        1/1     Running   0          34m
kube-system                 kube-controller-manager-kind-control-plane               1/1     Running   0          34m
kube-system                 kube-proxy-dqfg2                                         1/1     Running   0          34m
kube-system                 kube-scheduler-kind-control-plane                        1/1     Running   0          34m
local-path-storage          local-path-provisioner-78776bfc44-7zvxx                  1/1     Running   0          34m
seaweedfs-operator-system   seaweedfs-operator-controller-manager-54cc768f4c-cwz2k   1/1     Running   0          34m

See the next section for example usage - at this point you only deployed the Operator itself!

You need to also deploy a configuration to get it running (see next section)!

Configuration Examples

Basic SeaweedFS Deployment

For detailed configuration options and examples, see the sample configurations in the config/samples/ directory. For a line-by-line walkthrough of a full cluster, start with config/samples/seaweed_v1_seaweed_annotated.yaml.

Key fields explained

A Seaweed cluster is built from three core components, each run as its own StatefulSet. Every replicas value becomes that many Pods:

• master — coordinates the cluster and assigns volumes. Use 3 replicas for HA, 1 for dev.
• volume — stores the file data on disk. Each replica is a Pod with its own PersistentVolumeClaim(s). Lowering volume.replicas triggers a graceful scale-down: before removing a volume-server Pod the operator evacuates its data to the remaining servers (highest ordinal first, one at a time) and only deletes the Pod once the master confirms the server holds no volumes. A server whose data cannot be moved safely (e.g. no replication-compliant destination) blocks the scale-down rather than risking data loss.
• filer — serves the namespace and the S3/WebDAV/HTTP APIs.

Fields that commonly cause confusion:

• volume.requests.storage — the size of each volume-server PVC. This is where storage comes from: Kubernetes dynamically provisions a PersistentVolume of this size from the default StorageClass (or volume.storageClassName if set) and binds it to the Pod. To use specific or pre-provisioned disks, see config/samples/seaweed_v1_seaweed_existing_storage.yaml.

• volume.storageAnnotations / volume.storageLabels — stamped onto every generated volume-server PVC (the filer's metadata PVC takes the same under filer.persistence.annotations / .labels). Use these for CSI provisioners that read PVC annotations at provision time — e.g. NetApp Trident's trident.netapp.io/snapshotPolicy and snapshotReserve. Set them at cluster creation: StatefulSet volumeClaimTemplates are immutable, so changing them on a running cluster is not applied automatically — the operator emits a VolumeClaimTemplatesMismatch warning and you must recreate the StatefulSet (e.g. kubectl delete statefulset … --cascade=orphan, which keeps Pods and PVCs) before new PVCs pick up the change. Already-provisioned PVCs keep the metadata they were created with.

• volumeServerDiskCount — number of data disks (PVCs) attached to each volume-server Pod. They are mounted at /data0, /data1, … and passed to the volume server as -dir. Total PVCs = volume.replicas × volumeServerDiskCount. Leave at 1 unless a node exposes multiple disks.

• master.volumeSizeLimitMB — the max size of a single logical volume file before the master allocates a new one (1024 = 1 GiB per file). This is not the cluster capacity and not the PVC size — total capacity is driven by the volume servers' disks.

• hostSuffix — optional. Creates a single all-in-one Ingress exposing the cluster under filer.<hostSuffix>, s3.<hostSuffix>, and <name>-volume-<n>.<hostSuffix> (requires an Ingress controller). Omit it for in-cluster-only access, or use the per-component ingress: blocks for finer control.

• master.config / filer.config — raw TOML dropped verbatim into that component's config file (master.toml / filer.toml). Yes, you can paste an existing SeaweedFS filer config here — for example to point the filer's metadata store at Postgres/MySQL/Redis instead of local leveldb2.

• master.configSecret / filer.configSecret — the same TOML, but read from an existing Secret instead of the CR, so credentials in it (a metadata-store password, remote storage keys) stay out of kubectl get seaweed -o yaml, etcd and Git. The referenced key is mounted as master.toml / filer.toml, which lets External Secrets Operator, Sealed Secrets or SOPS own and rotate it. Set one of config or configSecret per component, not both — the API rejects it.

  filer:
    configSecret:
      name: seaweedfs-filer-config   # Secret in the same namespace
      key: filer.toml                # key inside it; any name works


  Rotating the Secret updates the mounted file in place, but SeaweedFS reads its TOML only at startup — restart the component's Pods (kubectl rollout restart statefulset/<name>-filer) for a change to take effect. Switching a component from config to configSecret also deletes the ConfigMap the operator generated for the inline config, so the plaintext copy does not linger in the namespace.

To run with a cloud bucket as remote storage (Cloud Drive) backed by a local cache, see config/samples/seaweed_v1_seaweed_remote_storage.yaml.

Bare-metal volume servers (DaemonSet + node-local disks)

By default volume servers run as a StatefulSet with one or more dynamically-provisioned PVCs per Pod. On on-prem / bare-metal clusters you often instead want one volume server per node, writing straight to that node's physical disks. Two volume fields enable this:

• volume.kind: DaemonSet — runs exactly one volume server on every node selected by the pod's nodeSelector / affinity / tolerations. replicas is ignored in this mode (the DaemonSet tracks the node set). The default, StatefulSet, is unchanged.
• volume.hostPath — a list of node-local directories to use as data directories. Each entry is mounted at /data0, /data1, … and passed to weed volume -dir, so a single server can span several physical disks. The optional per-entry maxVolumeCount caps volumes in that directory (0 = fill the disk); type defaults to DirectoryOrCreate. When set, no PVCs are created.

hostPath is required for kind: DaemonSet (DaemonSets cannot use volumeClaimTemplates) and the operator rejects the combination otherwise. It also works with a StatefulSet — pair it with node anti-affinity so two replicas never share a host directory.

spec:
  volume:
    kind: DaemonSet
    replicas: 0            # ignored for DaemonSet
    hostPath:
      - path: /mnt/disks/ssd0
        maxVolumeCount: 100
      - path: /mnt/disks/ssd1
    nodeSelector:
      seaweedfs.com/storage: "true"
    tolerations:
      - key: seaweedfs.com/storage
        operator: Exists
        effect: NoSchedule

See config/samples/seaweed_v1_seaweed_hostpath_daemonset.yaml for a full example. For rack/datacenter-aware placement across multiple volume groups, see TOPOLOGY_SUPPORT.md.

IAM Support

The operator supports IAM (Identity and Access Management) for S3 API authentication. IAM is embedded in the S3 server and runs on the same port (8333) as the S3 API.

For complete IAM configuration details, OIDC setup, and troubleshooting, see IAM_SUPPORT.md.

Example Configuration

apiVersion: seaweed.seaweedfs.com/v1
kind: Seaweed
metadata:
  name: seaweed-sample
  namespace: default
spec:
  image: chrislusf/seaweedfs:latest
  volumeServerDiskCount: 1
  hostSuffix: seaweed.abcdefg.com
  master:
    replicas: 3
    volumeSizeLimitMB: 1024
  volume:
    replicas: 1
    requests:
      storage: 2Gi
  filer:
    replicas: 2
    config: |
      [leveldb2]
      enabled = true
      dir = "/data/filerldb2"
  # Standalone S3 gateway — the preferred way to expose the S3 API. Creates a
  # "seaweed-sample-s3" Service on port 8333 (IAM is embedded on the same port
  # by default). See "S3 API" below.
  s3:
    replicas: 1

For more examples, see the config/samples/ directory:

• seaweed_v1_seaweed.yaml - Basic deployment with the standalone S3 gateway
• seaweed_v1_seaweed_annotated.yaml - Basic deployment with every field explained
• seaweed_v1_seaweed_existing_storage.yaml - Specific StorageClass / pre-provisioned PVs for local block storage
• seaweed_v1_seaweed_hostpath_daemonset.yaml - Bare-metal volume servers as a DaemonSet on node-local hostPath disks
• seaweed_v1_seaweed_remote_storage.yaml - Local cache plus a remote cloud bucket (Cloud Drive)
• seaweed_v1_seaweed_with_iam_embedded.yaml - S3 with embedded IAM
• seaweed_v1_seaweed_with_tls.yaml - mTLS between components via cert-manager
• seaweed_v1_seaweed_ingress_tls.yaml - Expose the S3 API and filer over TLS via per-component Ingress

S3 API

There are two ways to expose the S3 API. Prefer the standalone S3 gateway for new clusters.

Standalone S3 gateway (recommended) — set the top-level spec.s3 block. The operator runs S3 as its own stateless Deployment and puts a dedicated Service in front of it named <cluster-name>-s3 (for a cluster named seaweed1, the Service is seaweed1-s3), listening on port 8333:

spec:
  filer:
    replicas: 2          # the gateway dials the filer, so it must be enabled
  s3:
    replicas: 1          # stateless — scale freely
    # port: 8333         # override the default S3 port
    # domainName: s3.example.com   # for virtual-hosted-style buckets
    # metricsPort: 9327  # enable the Prometheus listener + a ServiceMonitor
    configSecret:        # optional: S3 identities (the -s3.config equivalent)
      name: my-s3-config
      key: seaweedfs_s3_config.json
    # service:           # optional: change the Service that fronts the gateway
    #   type: LoadBalancer
    #   annotations: {}
    # ingress:           # optional: per-component Ingress
    #   enabled: true

Reach it in-cluster at http://<cluster-name>-s3.<namespace>.svc:8333. To expose it externally, set spec.s3.service.type: LoadBalancer, add an spec.s3.ingress block (see Exposing the cluster via Ingress (TLS) below), or use the top-level hostSuffix, which publishes s3.<hostSuffix> over HTTP.

Embedded filer S3 (deprecated) — the older spec.filer.s3.enabled: true runs S3 inside every filer pod and exposes it as the filer-s3 port on the <cluster-name>-filer Service. There is no <cluster-name>-s3 Service in this mode. It is retained for backward compatibility but deprecated; the admission webhook rejects setting both paths at once and warns when the embedded path is used. Migrate by moving the config to the top-level spec.s3 block above.

IAM (S3 authentication) is embedded in the S3 server and runs on the same port. See IAM_SUPPORT.md.

Exposing the cluster via Ingress (TLS)

By default the operator only creates in-cluster Services. There are two ways to expose components (S3 API, filer, master/admin UIs, volume servers) outside the cluster through an Ingress controller. Both require an Ingress controller (ingress-nginx, Traefik, …) and DNS pointing at it.

• hostSuffix — the legacy all-in-one helper. One Ingress under filer.<hostSuffix>, s3.<hostSuffix>, and <name>-volume-<n>.<hostSuffix>. It is HTTP-only — it cannot terminate TLS.
• Per-component ingress: blocks — the recommended path, and the only one that supports TLS. Each component carries its own IngressSpec, so the S3 API and the filer can sit on different hostnames with different certificates.

The ingress: block is available on master, volume, filer, filer.s3Ingress (the filer's embedded S3 port), admin, and the standalone s3 and sftp gateways. Every block shares the same fields:

To reach the S3 API over an https:// URL, enable the S3 API and give it a TLS Ingress. With the filer-embedded S3 (filer.s3.enabled):

spec:
  filer:
    replicas: 1
    s3:
      enabled: true            # S3 API on port 8333 (IAM embedded)
    s3Ingress:
      enabled: true
      className: nginx
      host: s3.seaweed.example.com
      annotations:
        # cert-manager issues the cert into secretName below; omit if you
        # created the TLS Secret by hand.
        cert-manager.io/cluster-issuer: letsencrypt-prod
        nginx.ingress.kubernetes.io/proxy-body-size: "0"   # allow large S3 PUTs
      tls:
        - hosts: [s3.seaweed.example.com]
          secretName: seaweed-s3-tls

If you are not using cert-manager, create the TLS Secret yourself and drop the issuer annotation:

kubectl create secret tls seaweed-s3-tls --cert=tls.crt --key=tls.key

Then point any S3 client at the TLS endpoint:

aws --endpoint-url https://s3.seaweed.example.com s3 ls

Prefer the standalone S3 gateway (scales independently of the filer) by putting the same ingress: block under the top-level s3: instead of filer.s3Ingress — the fields are identical. See config/samples/seaweed_v1_seaweed_ingress_tls.yaml for a complete manifest.

Note: this Ingress TLS terminates HTTPS at the Ingress controller. It is separate from spec.tls, which provisions cert-manager-issued mTLS between SeaweedFS components (master/volume/filer gRPC).

TLS Between Components (cert-manager)

The operator can provision mTLS between the SeaweedFS components (master, volume, filer, S3) using cert-manager, which must be installed in the cluster. When spec.tls.enabled is true, the operator creates a cert-manager Certificate covering every component's headless Service and renders a security.toml that wires mTLS into every gRPC endpoint. If the cert-manager CRDs are absent, the operator records a condition on the Seaweed CR and leaves TLS off instead of failing.

By default (no issuerRef) the operator provisions a self-signed Issuer + CA Certificate + CA Issuer chain owned by the Seaweed CR — no external issuer required:

spec:
  tls:
    enabled: true

To sign the server certificate from a cert-manager Issuer or ClusterIssuer you already manage, set issuerRef and the operator skips the self-signed chain:

spec:
  tls:
    enabled: true
    issuerRef:
      name: my-ca-issuer
      kind: ClusterIssuer      # or Issuer (the default)
      group: cert-manager.io   # default

Note: this spec.tls block configures mTLS between SeaweedFS components. It is independent of the operator's own admission-webhook serving certificate, which is covered under Installation → Manual.

See config/samples/seaweed_v1_seaweed_with_tls.yaml for a full example.

Declarative Buckets

The Bucket CRD (seaweed.seaweedfs.com/v1) provisions S3 buckets inside an existing Seaweed cluster. It mirrors the surface of weed shell s3.bucket.* and fs.configure so the same operations users run manually become declarative manifests that GitOps tools (FluxCD, ArgoCD, OpenTofu) can apply and reconcile.

A minimal bucket:

apiVersion: seaweed.seaweedfs.com/v1
kind: Bucket
metadata:
  name: photos
  namespace: media
spec:
  clusterRef:
    name: seaweed1
    namespace: default

Supported per-bucket configuration:

• versioning: Off (default), Enabled, Suspended. Once enabled, cannot return to Off — use Suspended to halt new versions while retaining version history.
• objectLock: enable S3 Object Lock. Requires versioning: Enabled and is irreversible (matches S3 / SeaweedFS semantics).
• quota: cap total stored size with resource.Quantity (e.g. 100Gi) and toggle enforcement.
• owner / access: bind an existing IAM identity as bucket owner and grant per-user actions (Read, Write, List, Tagging, Admin). The IAM identity must already exist — the controller does not create users on your behalf.
• placement: pin replication, disk type, default TTL, fsync, WORM, read-only, data center / rack / data node, or pre-grow volumes for the bucket's collection. Collection name always equals the bucket name and is not configurable.
• reclaimPolicy: Retain (default) leaves data untouched on CR delete; Delete removes the bucket on CR delete (refused while Object Lock retention applies). Delete only removes a bucket this CR actually created or adopted — a CR whose adoption was refused (BucketAlreadyExists) never deletes a bucket another resource owns.
• adoptExisting: false (default) refuses a pre-existing bucket of the same name (condition BucketAlreadyExists, phase Failed); true adopts it and reconciles the spec onto it. This is the recovery path when a CR deleted under Retain is reapplied — the normal GitOps flow after an accidental deletion. Adoption confers full ownership, including deletion under reclaimPolicy: Delete.
• Cross-namespace clusterRef is denied by default: it resolves only when a ResourceReferenceGrant in the target Seaweed's namespace permits it. The bucket stays Pending (condition ClusterRefForbidden=True) until a grant exists. Same-namespace references never need a grant. Layer Kubernetes RBAC on the Bucket resource on top if you also want to restrict who can create Buckets in the first place.

CEL admission validations enforce: S3-compliant bucket-name regex, the objectLock ↔ versioning interlock, immutability of objectLock once enabled, and the "no return to Off" versioning transition rule.

See the config/samples/seaweed_v1_bucket*.yaml files for end-to-end examples (minimal, full-featured, object lock, cross-namespace).

Usage stats

The operator periodically refreshes status.usage (object count, total bytes, last-updated timestamp) on every Bucket by issuing one collection.list call per Seaweed cluster and patching each bucket's status. The cadence is configurable via the --bucket-usage-refresh-interval flag (default 5m). Set to 0 to disable. The loop is leader-elected so HA deployments do not duplicate work.

Usage stats are best-effort observation — they do not block reconcile or affect quota enforcement (the underlying S3 quota check on writes is authoritative). When a Bucket has not been successfully reconciled yet (status.bucketName empty), it is skipped until the main reconcile loop has provisioned it.

COSI coexistence

The SeaweedFS COSI driver also creates buckets via the upstream objectstorage.k8s.io/v1alpha1 API. The two are complementary: COSI is the right choice when an application needs a bucket-claim lifecycle bound to a workload, while the Bucket CRD is the right choice for cluster- or platform-team-owned buckets with quotas, placement, and IAM grants. The controller never adopts or modifies a bucket created by the COSI driver unless adoptExisting: true explicitly opts in — collisions are surfaced as BucketAlreadyExists in status rather than silently overwriting.

Bucket lifecycle policies

The BucketLifecyclePolicy CRD (seaweed.seaweedfs.com/v1) manages the S3 lifecycle configuration of a bucket declaratively, so object expiration and cleanup rules live in Git instead of being applied through the S3 API by hand.

apiVersion: seaweed.seaweedfs.com/v1
kind: BucketLifecyclePolicy
metadata:
  name: expire-logs
  namespace: media
spec:
  bucketRef:
    name: photos
  rules:
    - id: expire-archived
      prefix: archived/
      status: Enabled
      expiration:
        days: 90
    - id: cleanup-incomplete-uploads
      status: Enabled
      abortIncompleteMultipartUpload:
        daysAfterInitiation: 7

• bucketRef points at a Bucket in the same namespace; the cluster and the resolved bucket name are taken from it. The policy stays Pending until that bucket is provisioned. bucketRef is immutable.
• Each rule needs an id and at least one action: expiration (days, expiredObjectDeleteMarker), noncurrentVersionExpiration (noncurrentDays, newerNoncurrentVersions), or abortIncompleteMultipartUpload (daysAfterInitiation). prefix scopes a rule to a key prefix; status toggles it (Enabled default).
• A single policy owns a bucket's whole lifecycle configuration — the controller reconciles the bucket to exactly the listed rules. If more than one policy targets the same bucket, the oldest owns it and the rest are marked with a Conflict condition and left inactive.
• reclaimPolicy: Delete (default) removes the rules from the bucket when the CR is deleted; Retain leaves them in place.
• Taking over a bucket that used the older per-path day-TTL lifecycle (filer.conf TTL entries) clears those entries so expiration is driven only by the rules declared here.

See config/samples/seaweed_v1_bucketlifecyclepolicy.yaml for a full example.

Declarative IAM (identities, credentials, policies)

Four CRDs (seaweed.seaweedfs.com/v1) manage the S3 IAM objects of a Seaweed cluster declaratively, so users, access keys, and permissions can be GitOps-managed alongside the Bucket CRD. They drive the cluster's embedded IAM service (the IAM gRPC API on the filer — see IAM_SUPPORT.md) and mirror weed shell's s3.user.*, s3.accesskey.*, and s3.policy* commands.

Unlike Bucket (which holds data and defaults to reclaimPolicy: Retain), these resources are pure configuration: the CR is the source of truth, so they default to reclaimPolicy: Delete — deleting the CR removes the underlying IAM object. Set reclaimPolicy: Retain to opt out.

• S3Identity — an IAM user. Created with no credentials by default; optionally carries account (display name / e-mail) and a disabled flag. The user name defaults to metadata.name (override with spec.name, which is immutable once set).

  apiVersion: seaweed.seaweedfs.com/v1
  kind: S3Identity
  metadata: { name: alice, namespace: default }
  spec:
    seaweedRef: { name: seaweed1 }


• S3Credentials — an access key / secret key pair for an identity, mirrored into a Kubernetes Secret. If the referenced Secret is absent or empty the operator generates a key pair and writes it (the operator-created Secret is annotated as managed and removed with the CR under reclaimPolicy: Delete); if the Secret already holds both keys they are adopted and registered on the identity. A user-managed Secret is never deleted by the controller. The secret key is written only to the Secret, never to status.

  apiVersion: seaweed.seaweedfs.com/v1
  kind: S3Credentials
  metadata: { name: alice-creds, namespace: default }
  spec:
    seaweedRef: { name: seaweed1 }
    identityRef: { name: alice }
    secretRef: { name: alice-s3-secret }   # accessKeyField/secretKeyField default to accessKey/secretKey


• S3Policy — an IAM policy. Author it as structured statements (assembled into an AWS-style document) or supply a raw policyDocument JSON string for full control — exactly one is required. In statements, actions are S3 actions (s3:GetObject, …; * is shorthand for s3:*) and resources accept bucket-relative shorthand (my-bucket, my-bucket/*), expanded to arn:aws:s3:::… ARNs.

  apiVersion: seaweed.seaweedfs.com/v1
  kind: S3Policy
  metadata: { name: rw-uploads, namespace: default }
  spec:
    seaweedRef: { name: seaweed1 }
    statements:
      - effect: Allow
        actions: [s3:GetObject, s3:PutObject, s3:DeleteObject]
        resources: [my-bucket/uploads/*]


• S3PolicyBinding — attaches a policy to a set of identities. The controller reconciles to exactly the listed subjects; identities removed from the list have the policy detached (the identity itself is left intact).

  apiVersion: seaweed.seaweedfs.com/v1
  kind: S3PolicyBinding
  metadata: { name: alice-uploads, namespace: default }
  spec:
    seaweedRef: { name: seaweed1 }
    policyRef: { name: rw-uploads }
    subjects:
      - { kind: S3Identity, name: alice }
      - { kind: S3Identity, name: bob }


IAM user and policy names are global to the cluster while these CRs are namespaced:

• Name conflicts — when CRs in different namespaces claim the same IAM name on the same cluster, the oldest claim owns it; later claimants are marked Failed with a Ready=False / reason: Conflict condition naming the owning CR. Set spec.name to give each namespace a distinct IAM name.
• Reference resolution — identityRef, policyRef, and subjects name the referenced S3Identity / S3Policy resource in the same namespace and follow its effective IAM name, so a spec.name override stays transparent to referencing resources. A name with no matching resource is used as the IAM name directly, which keeps references to IAM objects not managed by any CR (and pre-existing manifests) working. Once provisioned, the resolved name is pinned in status so a resource created later under the same name cannot silently retarget the credential or binding.

S3Credentials and S3PolicyBinding wait (status Pending) until the identity / policy they reference exists, so apply order does not matter. As with Bucket, a cross-namespace seaweedRef (and the S3Credentials secretRef) is denied by default and requires a ResourceReferenceGrant in the target namespace. When the filer enforces jwt.filer_signing.key (rendered into the cluster's security.toml whenever a filer or admin is in spec), the operator reads that key and signs its own IAM gRPC calls with it, so authenticated filers are handled automatically.

See the config/samples/seaweed_v1_s3*.yaml files for end-to-end examples.

Cross-namespace references (ResourceReferenceGrant)

By default a SeaweedFS resource may only reference resources in its own namespace. A reference that crosses namespaces — a Bucket/S3* seaweedRef/clusterRef pointing at a Seaweed in another namespace, or an S3Credentials secretRef pointing at a Secret in another namespace — is refused until the target namespace publishes a ResourceReferenceGrant that allows it. This mirrors the Gateway API ReferenceGrant: the namespace that owns the resource being pointed at — not the requester — decides who may reach in.

The grant lives in the namespace of the resource being referenced. Its spec.from lists the trusted sources — each names a {group, kind} plus the source namespaces, given either as an exact namespace or as a namespaceSelector (exactly one per entry) — and its spec.to lists the {group, kind, name?} referents in that namespace (omit name to allow every resource of that kind). A reference is allowed when it matches at least one from and one to entry.

# In the cluster's namespace: let the "media" namespace's Buckets and
# S3Credentials reference the Seaweed cluster "prod".
apiVersion: seaweed.seaweedfs.com/v1
kind: ResourceReferenceGrant
metadata:
  name: allow-media
  namespace: seaweedfs
spec:
  from:
    - { group: seaweed.seaweedfs.com, kind: Bucket, namespace: media }
    - { group: seaweed.seaweedfs.com, kind: S3Credentials, namespace: media }
  to:
    - { group: seaweed.seaweedfs.com, kind: Seaweed }   # any Seaweed here

For environments where source namespaces are created on demand (per tenant, per PR, ...) and cannot be enumerated ahead of time, a from entry may select namespaces by label with namespaceSelector instead of naming one. Every namespace whose labels match is trusted, so labelling a freshly created namespace grants access without editing the grant. An empty selector ({}) matches all namespaces.

# Trust every namespace labelled seaweedfs-access=true to reference any
# Seaweed cluster in this namespace.
apiVersion: seaweed.seaweedfs.com/v1
kind: ResourceReferenceGrant
metadata:
  name: allow-labeled-buckets
  namespace: seaweedfs
spec:
  from:
    - group: seaweed.seaweedfs.com
      kind: Bucket
      namespaceSelector:
        matchLabels: { seaweedfs-access: "true" }
  to:
    - { group: seaweed.seaweedfs.com, kind: Seaweed }

While a required grant is missing the referencing resource stays Pending (Bucket surfaces condition ClusterRefForbidden=True; the S3* kinds surface ReferenceGranted=False) and reconciles to ready automatically once the grant is created — at which point the condition is cleared.

Enforcement is reconcile-time and eventually consistent (like every cross-resource dependency here, and like Gateway API): revoking a grant stops the operator from (re)provisioning the reference on the next reconcile, but does not retroactively tear down objects already provisioned under it. Deleting a resource is never blocked by a missing grant, so revoking one cannot strand a finalizer. See config/samples/seaweed_v1_resourcereferencegrant.yaml.

CSI Driver (mount volumes as PersistentVolumes)

The operator can also deploy the seaweedfs-csi-driver so that pods mount a SeaweedFS filer as ordinary PersistentVolumes (a POSIX FUSE mount), including ReadWriteMany volumes shared across nodes. This is the filesystem alternative to the S3 API above.

A CSI driver is node-global, so it is managed through its own opt-in SeaweedCSIDriver resource rather than a field on the Seaweed CR, and the controller is off by default — enable it with ENABLE_CSI_DRIVER=true on the operator manager. The driver can mount an operator-managed cluster (seaweedRef, grant-gated across namespaces) or any external filer (filerAddress):

apiVersion: seaweed.seaweedfs.com/v1
kind: SeaweedCSIDriver
metadata:
  name: seaweedfs
spec:
  seaweedRef:
    name: seaweed1
  storageClass:
    name: seaweedfs
    parameters:
      replication: "000"

Pods then request a PVC against the seaweedfs StorageClass. See CSI_SUPPORT.md for the full guide, API reference, and the list of managed objects. Example: config/samples/seaweed_v1_seaweedcsidriver.yaml.

Scheduled admin scripts (AdminScript)

The AdminScript CRD (seaweed.seaweedfs.com/v1) runs a weed shell script on a cron schedule against a cluster — for recurring maintenance such as volume.balance, volume.fix.replication, ec.encode, or volume.vacuum. The operator reconciles each AdminScript into a native Kubernetes CronJob in the same namespace, owned by the CR (so deleting the AdminScript removes the CronJob). Each run pipes the script into weed shell -master=<cluster masters> (and -filer=<cluster filer> when the cluster runs a filer). The run pod mirrors the cluster's admin/worker pods — it uses the cluster image and, when the cluster has mTLS enabled, mounts the same security.toml/TLS material so the shell authenticates to the masters over gRPC.

apiVersion: seaweed.seaweedfs.com/v1
kind: AdminScript
metadata:
  name: nightly-balance
  namespace: default
spec:
  clusterRef:
    name: seaweed-sample        # a Seaweed CR in the same namespace
  schedule: "0 2 * * *"         # daily at 02:00
  script: |
    lock
    volume.balance -force
    volume.fix.replication
    unlock

• concurrencyPolicy defaults to Forbid so overlapping maintenance runs never stack up; suspend: true pauses scheduling without deleting the CR.
• successfulJobsHistoryLimit / failedJobsHistoryLimit / backoffLimit / activeDeadlineSeconds / startingDeadlineSeconds / timeZone are passed through to the generated CronJob/Job.
• image overrides the container image (defaults to the cluster's image), and credentialsSecret projects a Secret's keys into the run pod as environment variables for scripts that need them (defaults to the cluster's admin credentialsSecret when set).
• Status surfaces phase (Pending/Active/Suspended), the managed cronJobName, and the CronJob's lastScheduleTime/lastSuccessfulTime.

kubectl get adminscripts (short name swas) lists them. Example: config/samples/seaweed_v1_adminscript.yaml.

Maintenance and Uninstallation

• TBD

Development

Follow the instructions in https://sdk.operatorframework.io/docs/building-operators/golang/quickstart/

# install and prepare kind-cluster for development
make kind-prepare

# build the operator image and load the image into Kind cluster
make kind-load

# deploy operator and CRDs
make deploy

# install example of CR
kubectl apply -f config/samples/seaweed_v1_seaweed.yaml

# or install example with S3 and embedded IAM
kubectl apply -f config/samples/seaweed_v1_seaweed_with_iam_embedded.yaml

Testing IAM Functionality

To test the embedded IAM implementation:

# Run IAM-specific tests
go test -v -run "Filer.*IAM|IAM.*Filer" ./internal/controller

# Run all tests
make test

Update the Operator

# rebuild and re-upload image to the kind
make kind-load

# redeploy operator and CRDs
make redeploy

Develop outside of k8s

# register the CRD with the Kubernetes cluster
make install

# run the operator locally outside the Kubernetes cluster
make run ENABLE_WEBHOOKS=false

# From another terminal in the same directory
kubectl apply -f config/samples/seaweed_v1_seaweed.yaml
