traefik/traefik-library-image

Traefik is a modern HTTP reverse proxy and ingress controller that makes deploying microservices easy.

Traefik integrates with your existing infrastructure components (Kubernetes, Docker, Swarm, Consul, Nomad, etcd, Amazon ECS, ...) and configures itself automatically and dynamically.

Pointing Traefik at your orchestrator should be the only configuration step you need.

Traefik v3 - Example usage

Enable docker provider and dashboard UI:

## traefik.yml

# Docker configuration backend
providers:
  docker:
    defaultRule: "Host(`{{ trimPrefix `/` .Name }}.docker.localhost`)"

# API and dashboard configuration
api:
  insecure: true

Start Traefik v3:

docker run -d -p 8080:8080 -p 80:80 \
  -v $PWD/traefik.yml:/etc/traefik/traefik.yml \
  -v /var/run/docker.sock:/var/run/docker.sock \
  traefik:v3

Start a backend server using the traefik/whoami image:

docker run -d --name test traefik/whoami

Access the whoami service through Traefik via the defined rule test.docker.localhost:

$ curl test.docker.localhost
Hostname: 0693100b16de
IP: 127.0.0.1
IP: ::1
IP: 192.168.215.4
RemoteAddr: 192.168.215.3:57618
GET / HTTP/1.1
Host: test.docker.localhost
User-Agent: curl/8.7.1
Accept: */*
Accept-Encoding: gzip
X-Forwarded-For: 192.168.215.1
X-Forwarded-Host: test.docker.localhost
X-Forwarded-Port: 80
X-Forwarded-Proto: http
X-Forwarded-Server: 8a37fd4f35fb
X-Real-Ip: 192.168.215.1

Access the Traefik Dashboard:

Open your web browser and navigate to http://localhost:8080 to access the Traefik dashboard. This will provide an overview of routers, services, and middlewares.

Traefik v2 - Example usage

Enable docker provider and dashboard UI:

## traefik.yml

# Docker configuration backend
providers:
  docker:
    defaultRule: "Host(`{{ trimPrefix `/` .Name }}.docker.localhost`)"

# API and dashboard configuration
api:
  insecure: true

Start Traefik v2:

docker run -d -p 8080:8080 -p 80:80 \
-v $PWD/traefik.yml:/etc/traefik/traefik.yml \
-v /var/run/docker.sock:/var/run/docker.sock \
traefik:v2.11

Start a backend server using the traefik/whoami image:

docker run -d --name test traefik/whoami

Access the whoami service through Traefik via the defined rule test.docker.localhost:

$ curl test.docker.localhost
Hostname: 390a880bdfab
IP: 127.0.0.1
IP: 172.17.0.3
GET / HTTP/1.1
Host: test.docker.localhost
User-Agent: curl/7.65.3
Accept: */*
Accept-Encoding: gzip
X-Forwarded-For: 172.17.0.1
X-Forwarded-Host: test.docker.localhost
X-Forwarded-Port: 80
X-Forwarded-Proto: http
X-Forwarded-Server: 7e073cb54211
X-Real-Ip: 172.17.0.1

Access the Traefik Dashboard:

Open your web browser and navigate to http://localhost:8080 to access the Traefik dashboard. This will provide an overview of routers, services, and middlewares.

Documentation

You can find the complete documentation:

• for v3.x
• for v2.11

A community support is available at https://community.traefik.io
