#Axonometric Projection Engine

A simple, lightweight 2.5D Axonometric Projection Engine (APE). A demo of APE in action can be found here.

• APE consists of just 2 components - Scene & Nodes:

    var myScene = new AP.Scene();
    var myNode = new AP.Node();


• A Node can be added as a child to a Scene, or to another Node:

    myScene.addChild(myNode);
    myParentNode.addChild(myChildNode);


• A Scene can be both rotated & pitched:

    myScene.rotate(45);
    myScene.pitch(35);


• A Node can be translated, rotated & scaled:

    // Transformation methods
    myNode.translate(50, 200, 0);
    myNode.rotate(45, 90, 0);
    myNode.scale(0.5, 2, 1);

    // Transformation properties
    myNode.x = 100;
    myNode.y = 200;
    myNode.z = 300;
    myNode.scaleX = 2;
    myNode.scaleY = 2;
    myNode.scaleZ = 2;
    myNode.rotationX = 45;
    myNode.rotationY = 15;
    myNode.rotationZ = 145;


• Nested Nodes inherit their parent's transformations.

• Nodes can also be configured to rotate about their local coordinate space. This property is useful for walking or flying Nodes around a Scene:

    myNode.localRotation = true;


• Nodes are projected from their 3D Scene coordinate to a 2D Screen coordinate by calling:

    // Project a single Node instance
    myNode.project();

    // Recursively loop through all Nodes in a Scene, calling project() on each of them
    myScene.projectNodes();


• Once projected, you can use the Node's .px and .py properties:

    // Position a DOM element
    myElement.style.left = myNode.px + 'px';
    myElement.style.top = myNode.py + 'px';

    Draw a line to a canvas
    myCanvasContext.drawLine(myNode.px, myNode.py);


• Nodes can also be sorted by z-depth:

    myScene.sortNodes();


• This method calculates and incrementally sets the zIndex property on every Node in a Scene so that you can easily set a DOM element’s z-index property:

    myElement.style.zIndex = myNode.zIndex;


• In special cases, you may want to take control over the z-order of Nodes that have equal z-depths. To accomplish this, Nodes have a z-priority property that can be assigned like so:

    myForegroundNode.zPriority = 1;
    myBackgroundNode.zPriority = 0;


• This configuration would result in myForegroundNode always having a higher zIndex than myBackgroundNode when their zDepths are equal.

• Furthermore, you can also manipulate the calculated zDepth property of each Node by specifying a value for the z-offset property:

    myNode.zOffset = 100;


• This would add an additional 100 units to the calculated z-depth value, pushing the Node up the stack when sorting Nodes in the Scene.

##Example:

// Create instance variables.
var canvas = document.getElementById('canvas');
var canvasWidth = parseInt(canvas.attributes.width.value, 10);
var canvasHeight = parseInt(canvas.attributes.height.value, 10);
var context = canvas.getContext('2d');
var scene = new APE.Scene();
var nodeA = new APE.Node();
var nodeB = new APE.Node();

// Configure the scene.
scene.setOrigin(canvasWidth/2, canvasHeight/2);
scene.rotate(45);
scene.pitch(30);

// Configure the display hierarchy.
scene.addChild(nodeA);
nodeA.addChild(nodeB);

// Transform the nodes.
nodeA.x = 50;
nodeA.rotate(20, 45, 0);
nodeB.translate(0, 100, 50);
nodeB.scaleY = 2;

// Project the nodes in the scene.
scene.projectNodes();

// Draw the result to the canvas.
context.moveTo(scene.origin.x, scene.origin.y);
context.lineTo(nodeA.px, nodeA.py);
context.lineTo(nodeB.px, nodeB.py);
context.stroke();

For a more complex example of what can be done with APE, check out the demo here.

##Author:

Matthew Wagerfield: @mwagerfield

##License

Licensed under MIT. Enjoy.
