blessed-contrib
Build dashboards (or any other application) using ascii/ansi art and javascript.
Friendly to terminals, ssh and developers. Extends blessed with custom drawille and other widgets.
You should also check WOPR: a markup for creating terminal reports, presentations and infographics.
Contributors:
Yaron Naveh (@YaronNaveh) Chris (@xcezzz) Miguel Valadas (@mvaladas) Liran Tal (@lirantal)
Demo (full size):
(source code)
Running the demo
git clone https://github.com/yaronn/blessed-contrib.git
cd blessed-contrib
npm install
node ./examples/dashboard.js
Works on Linux, OS X and Windows. For Windows follow the pre requisites.
Installation (to build custom projects)
Please use the latest stable version of Node.js LTS and install blessed-contrib and its peer dependency blessed as follows:
npm install blessed blessed-contrib
Usage
You can use any of the default widgets of blessed (texts, lists and etc) or the widgets added in blessed-contrib (described below). A layout is optional but useful for dashboards. The widgets in blessed-contrib follow the same usage pattern:
var blessed = require('blessed')
, contrib = require('blessed-contrib')
, screen = blessed.screen()
, line = contrib.line(
{ style:
{ line: "yellow"
, text: "green"
, baseline: "black"}
, xLabelPadding: 3
, xPadding: 5
, label: 'Title'})
, data = {
x: ['t1', 't2', 't3', 't4'],
y: [5, 1, 7, 5]
}
screen.append(line) //must append before setting data
line.setData([data])
screen.key(['escape', 'q', 'C-c'], function(ch, key) {
return process.exit(0);
});
screen.render()
See below for a complete list of widgets.
Widgets
Line Chart
Bar Chart
Stacked Bar Chart
Map
Gauge
Stacked Gauge
Donut
LCD Display
Rolling Log
Sparkline
Table
Tree
Markdown
Line Chart
var line = contrib.line(
{ style:
{ line: "yellow"
, text: "green"
, baseline: "black"}
, xLabelPadding: 3
, xPadding: 5
, showLegend: true
, wholeNumbersOnly: false //true=do not show fraction in y axis
, label: 'Title'})
var series1 = {
title: 'apples',
x: ['t1', 't2', 't3', 't4'],
y: [5, 1, 7, 5]
}
var series2 = {
title: 'oranges',
x: ['t1', 't2', 't3', 't4'],
y: [2, 1, 4, 8]
}
screen.append(line) //must append before setting data
line.setData([series1, series2])
Examples: simple line chart, multiple lines, 256 colors
Bar Chart
var bar = contrib.bar(
{ label: 'Server Utilization (%)'
, barWidth: 4
, barSpacing: 6
, xOffset: 0
, maxHeight: 9})
screen.append(bar) //must append before setting data
bar.setData(
{ titles: ['bar1', 'bar2']
, data: [5, 10]})
Stacked Bar Chart
bar = contrib.stackedBar(
{ label: 'Server Utilization (%)'
, barWidth: 4
, barSpacing: 6
, xOffset: 0
//, maxValue: 15
, height: "40%"
, width: "50%"
, barBgColor: [ 'red', 'blue', 'green' ]})
screen.append(bar)
bar.setData(
{ barCategory: ['Q1', 'Q2', 'Q3', 'Q4']
, stackedCategory: ['US', 'EU', 'AP']
, data:
[ [ 7, 7, 5]
, [8, 2, 0]
, [0, 0, 0]
, [2, 3, 2] ]
})
Map
var map = contrib.map({label: 'World Map'})
map.addMarker({"lon" : "-79.0000", "lat" : "37.5000", color: "red", char: "X" })
Gauge
var gauge = contrib.gauge({label: 'Progress', stroke: 'green', fill: 'white'})
gauge.setPercent(25)
Stacked Gauge
Either specify each stacked portion with a percent and stroke...
var gauge = contrib.gauge({label: 'Stacked '})
gauge.setStack([{percent: 30, stroke: 'green'}, {percent: 30, stroke: 'magenta'}, {percent: 40, stroke: 'cyan'}])
Or, you can just supply an array of numbers and random colors will be chosen.
var gauge = contrib.gauge({label: 'Stacked Progress'})
gauge.setStack([30,30,40])
Donut
var donut = contrib.donut({
label: 'Test',
radius: 8,
arcWidth: 3,
remainColor: 'black',
yPadding: 2,
data: [
{percent: 80, label: 'web1', color: 'green'}
]
});
Data passed in uses percent and label to draw the donut graph. Color is optional and defaults to green.
donut.setData([
{percent: 87, label: 'rcp','color': 'green'},
{percent: 43, label: 'rcp','color': 'cyan'},
]);
Updating the donut is as easy as passing in an array to setData using the same array format as in the constructor. Pass in as many objects to the array of data as you want, they will automatically resize and try to fit. However, please note that you will still be restricted to actual screen space.
You can also hardcode a specific numeric into the donut's core display instead of the percentage by passing an percentAltNumber property to the data, such as:
var donut = contrib.donut({
label: 'Test',
radius: 8,
arcWidth: 3,
remainColor: 'black',
yPadding: 2,
data: [
{percentAltNumber: 50, percent: 80, label: 'web1', color: 'green'}
]
});
See an example of this in one of the donuts settings on ./examples/donut.js.
LCD Display
var lcd = contrib.lcd(
{ segmentWidth: 0.06 // how wide are the segments in % so 50% = 0.5
, segmentInterval: 0.11 // spacing between the segments in % so 50% = 0.550% = 0.5
, strokeWidth: 0.11 // spacing between the segments in % so 50% = 0.5
, elements: 4 // how many elements in the display. or how many characters can be displayed.
, display: 321 // what should be displayed before first call to setDisplay
, elementSpacing: 4 // spacing between each element
, elementPadding: 2 // how far away from the edges to put the elements
, color: 'white' // color for the segments
, label: 'Storage Remaining'})
lcd.setDisplay(23 + 'G'); // will display "23G"
lcd.setOptions({}) // adjust options at runtime
Please see the examples/lcd.js for an example. The example provides keybindings to adjust the segmentWidth and segmentInterval and strokeWidth in real-time so that you can see how they manipulate the look and feel.
Rolling Log
var log = contrib.log(
{ fg: "green"
, selectedFg: "green"
, label: 'Server Log'})
log.log("new log line")
(Also check the new blessed image implementation which has several benefits over this one.)
var pic = contrib.picture(
{ file: './flower.png'
, cols: 25
, onReady: ready})
function ready() {screen.render()}
note: only png images are supported
Sparkline
var spark = contrib.sparkline(
{ label: 'Throughput (bits/sec)'
, tags: true
, style: { fg: 'blue' }})
sparkline.setData(
[ 'Sparkline1', 'Sparkline2'],
[ [10, 20, 30, 20]
, [40, 10, 40, 50]])
Table
var table = contrib.table(
{ keys: true
, fg: 'white'
, selectedFg: 'white'
, selectedBg: 'blue'
, interactive: true
, label: 'Active Processes'
, width: '30%'
, height: '30%'
, border: {type: "line", fg: "cyan"}
, columnSpacing: 10 //in chars
, columnWidth: [16, 12, 12] /*in chars*/ })
//allow control the table with the keyboard
table.focus()
table.setData(
{ headers: ['col1', 'col2', 'col3']
, data:
[ [1, 2, 3]
, [4, 5, 6] ]})
Tree
var tree = contrib.tree({fg: 'green'})
//allow control the table with the keyboard
tree.focus()
tree.on('select',function(node){
if (node.myCustomProperty){
console.log(node.myCustomProperty);
}
console.log(node.name);
}
// you can specify a name property at root level to display root
tree.setData(
{ extended: true
, children:
{
'Fruit':
{ children:
{ 'Banana': {}
, 'Apple': {}
, 'Cherry': {}
, 'Exotics': {
children:
{ 'Mango': {}
, 'Papaya': {}
, 'Kiwi': { name: 'Kiwi (not the bird!)', myCustomProperty: "hairy fruit" }
}}
, 'Pear': {}}}
, 'Vegetables':
{ children:
{ 'Peas': {}
, 'Lettuce': {}
, 'Pepper': {}}}}})
Options
- keys : Key to expand nodes. Default : ['enter','default']
- extended : Should nodes be extended/generated by default? Be careful with this setting when using a callback function. Default : false
- template :
- extend : Suffix "icon" for closed node. Default : '[+]'
- retract : Suffix "icon" for opened node. Default : '[-]'
- lines : Show lines in tree. Default : true
Nodes
Every node is a hash and it can have custom properties that can be used in "select" event callback. However, there are several special keys :
- name
- Type :
string - Desc : Node name
- If the node isn't the root and you don't specify the name, will be set to hash key
- Example :
{ name: 'Fruit'}
- Type :
- children
- Type :
hashorfunction(node){ return children } - Desc : Node children.
- The function must return a hash that could have been used as children property
- If you use a function, the result will be stored in
node.childrenContentandchildren - Example :
- Hash :
{'Fruit':{ name: 'Fruit', children:{ 'Banana': {}, 'Cherry': {}}}} - Function : see
examples/explorer.js
- Hash :
- Type :
- childrenContent
- Type :
hash - Desc : Children content for internal usage DO NOT MODIFY
- If
node.childrenis a hash,node.children===node.childrenContent - If
node.childrenis a function, it's used to store thenode.children()result - You can read this property, but you should never write it.
- Usually this will be used to check
if(node.childrenContent)in yournode.childrenfunction to generate children only once
- Type :
- extended
- Type :
boolean - Desc : Determine if this node is extended
- No effect when the node have no child
- Default value for each node will be
treeInstance.options.extendedif the nodeextendedoption is not set - Example :
{'Fruit':{ name: 'Fruit', extended: true, children:{ 'Banana': {}, 'Cherry': {}}}}
- Type :
Markdown
var markdown = contrib.markdown()
markdown.setMarkdown('# Hello \n blessed-contrib renders markdown using `marked-terminal`')
Colors
You can use 256 colors (source):
function randomColor() {
return [Math.random() * 255,Math.random()*255, Math.random()*255]
}
line = contrib.line(
{
...
, style: { line: randomColor(), text: randomColor(), baseline: randomColor() }
})
Layouts
Grid
Carousel
Grid
A grid layout can auto position your elements in a grid layout. When using a grid, you should not create the widgets, rather specify to the grid which widget to create and with which params. Each widget can span multiple rows and columns.
var screen = blessed.screen()
var grid = new contrib.grid({rows: 12, cols: 12, screen: screen})
//grid.set(row, col, rowSpan, colSpan, obj, opts)
var map = grid.set(0, 0, 4, 4, contrib.map, {label: 'World Map'})
var box = grid.set(4, 4, 4, 4, blessed.box, {content: 'My Box'})
screen.render()
Carousel
A carousel layout switches between different views based on time or keyboard activity. One use case is an office dashboard with rotating views:
var blessed = require('blessed')
, contrib = require('./')
, screen = blessed.screen()
function page1(screen) {
var map = contrib.map()
screen.append(map)
}
function page2(screen) {
var line = contrib.line(
{ width: 80
, height: 30
, left: 15
, top: 12
, xPadding: 5
, label: 'Title'
})
var data = [ { title: 'us-east',
x: ['t1', 't2', 't3', 't4'],
y: [0, 0.0695652173913043, 0.11304347826087, 2],
style: {
line: 'red'
}
}
]
screen.append(line)
line.setData(data)
}
screen.key(['escape', 'q', 'C-c'], function(ch, key) {
return process.exit(0);
});
var carousel = new contrib.carousel( [page1, page2]
, { screen: screen
, interval: 3000 //how often to switch views (set 0 to never swicth automatically)
, controlKeys: true //should right and left keyboard arrows control view rotation
})
carousel.start()
Samples
Terminal Dashboard
Running the sample
git clone https://github.com/yaronn/blessed-contrib.git
cd blessed-contrib
npm install
node ./examples/dashboard.js
Installation (for a custom dashboard)
npm install blessed
npm install blessed-contrib
A simple dashboard
var blessed = require('blessed')
, contrib = require('blessed-contrib')
, screen = blessed.screen()
, grid = new contrib.grid({rows: 1, cols: 2, screen: screen})
var line = grid.set(0, 0, 1, 1, contrib.line,
{ style:
{ line: "yellow"
, text: "green"
, baseline: "black"}
, xLabelPadding: 3
, xPadding: 5
, label: 'Stocks'})
var map = grid.set(0, 1, 1, 1, contrib.map, {label: 'Servers Location'})
var lineData = {
x: ['t1', 't2', 't3', 't4'],
y: [5, 1, 7, 5]
}
line.setData([lineData])
screen.key(['escape', 'q', 'C-c'], function(ch, key) {
return process.exit(0);
});
screen.render()
Rich dashboard
See source code
Troubleshooting
If you see questions marks or some (or all) missign characters try running with these env vars to fix encoding / terminal:
$> LANG=en_US.utf8 TERM=xterm-256color node your-code.js
License
This library is under the MIT License
More Information
Created by Yaron Naveh (twitter, blog)
Related repositories
Master programming by recreating your favorite technologies from scratch.
A curated meta-list of curated lists organized by technology domain. The repository acts as a directory pointing to hundreds of specialized awesome lists covering programming languages, platforms, frameworks, and tooling. All content is community-contributed under the CC0 public domain dedication.
Public APIs is a community-curated GitHub repository listing free, publicly accessible APIs across a wide range of categories, with auth type, HTTPS, and CORS noted for each entry. It's a browsable reference, not a library to install.
freeCodeCamp is a free, self-paced curriculum for learning to code, published as open source at freeCodeCamp/freeCodeCamp. It's a 501(c)(3) nonprofit funded by donor support, structured around six certifications in its Full-Stack Developer Curriculum, each gated by required projects instead of open-book quizzes. The repository also carries beta language certifications for developers, interview-prep resources, and the code that runs the live freecodecamp.org platform.
Quick answers
Does yaronn/blessed-contrib have a project website?
No homepage URL was recorded for yaronn/blessed-contrib in TopGit's last sync. The README tab above frequently contains screenshots and demo links, or check the repository description on GitHub.
How many stars does yaronn/blessed-contrib have?
yaronn/blessed-contrib has 15.8k GitHub stars — refresh the page for the live number, or check github.com/yaronn/blessed-contrib. TopGit mirrors GitHub's count but does not claim minute-by-minute accuracy.
Is yaronn/blessed-contrib open source?
Yes — yaronn/blessed-contrib ships under the MIT license, which makes its source code freely readable (and, depending on license terms, forkable and reusable). Source: github.com/yaronn/blessed-contrib.
What is yaronn/blessed-contrib?
yaronn/blessed-contrib (yaronn/blessed-contrib) is a JavaScript project on GitHub. From the project's own README: Build terminal dashboards using ascii/ansi art and javascript
Where do I read more about yaronn/blessed-contrib?
This TopGit page is a snapshot — the READ ME tab shows the project's own README content (links stripped, images preserved). The GitHub repository at github.com/yaronn/blessed-contrib is the definitive source.
Read full README in the tab above.
Still deciding about blessed-contrib?
One click hands the question to an AI along with this page — see what it says about blessed-contrib.
