zhkl0228/unidbg

unidbg

Allows you to emulate an Android native library, and an experimental iOS emulation.

This is an educational project to learn more about the ELF/MachO file format and ARM assembly.

Use it at your own risk !

Features

• Support MCP (Model Context Protocol) for AI-assisted debugging with Cursor and other AI tools.
• Emulation of the JNI Invocation API so JNI_OnLoad can be called.
• Support JavaVM, JNIEnv.
• Emulation of syscalls instruction.
• Support ARM32 and ARM64.
• Inline hook, thanks to Dobby.
• Android import hook, thanks to xHook.
• iOS fishhook and substrate and whale hook.
• unicorn backend support simple console debugger, gdb stub, instruction trace, memory read/write trace.
• Support iOS objc and swift runtime.
• Support dynarmic fast backend.
• Support Apple M1 hypervisor, the fastest ARM64 backend.
• Support Linux KVM backend with Raspberry Pi B4.
• Memory leak detection for emulated native code with guest backtrace and host stack trace.

MCP Debugger (AI Integration)

unidbg supports Model Context Protocol (MCP) for AI-assisted debugging. When the debugger is active, type mcp in the console to start an MCP server that AI tools (e.g. Cursor) can connect to.

Quick Start

unidbg MCP has two operating modes:

Mode 1: Breakpoint Debug — Attach the debugger and run your code. When a breakpoint is hit, Breaker.debug() pauses the emulator — type mcp in the console to start MCP server and let AI assist with analysis. All debugging tools are available (registers, memory, disassembly, stepping, tracing, etc). After resuming, if another breakpoint is hit the debugger pauses again. Once execution completes without hitting a breakpoint, the process exits and MCP shuts down.

Debugger debugger = emulator.attach();
debugger.addBreakPoint(address);
// run your emulation logic — debugger pauses when breakpoint is hit

Mode 2: Custom Tools (Repeatable) — Use McpToolkit to register custom tools and let AI re-run target functions with different parameters. The native library is loaded once; after each execution the process stays alive and MCP remains active for the next run.

McpToolkit toolkit = new McpToolkit();
toolkit.addTool(new McpTool() {
    @Override public String name() { return "encrypt"; }
    @Override public String description() { return "Run encryption"; }
    @Override public String[] paramNames() { return new String[]{"input"}; }
    @Override public void execute(String[] params) {
        String input = params.length > 0 ? params[0] : "default";
        // call encryption with input
    }
});
toolkit.run(emulator.attach());

When the debugger breaks, type mcp (or mcp 9239 to specify port) in the console. Then add to Cursor MCP settings:

{
  "mcpServers": {
    "unidbg-mcp-server": {
      "url": "http://localhost:9239/sse"
    }
  }
}

Available MCP Tools

Status & Info

Registers & Disassembly

Memory

Breakpoints & Execution

Tracing

Function Calls

iOS Only (available when Family=iOS)

Custom MCP Tools

Use McpToolkit to register custom tools, each implementing the McpTool interface. This replaces manual if-else dispatch with clean, self-contained tool classes. By this point the native library is fully loaded (JNI_OnLoad / entry point already executed), so the code inside each tool's execute() is the target function logic to analyze. AI can set breakpoints and traces before triggering a custom tool, then inspect execution results across different inputs without restarting the process.

Android Example — See Utilities64.java for an Android JNI example with custom MCP tools:

DalvikModule dm = vm.loadLibrary(new File("libtmessages.29.so"), true);
dm.callJNI_OnLoad(emulator);
cUtilities = vm.resolveClass("org/telegram/messenger/Utilities");

McpToolkit toolkit = new McpToolkit();
toolkit.addTool(new McpTool() {
    @Override public String name() { return "aesCbc"; }
    @Override public String description() { return "Run AES-CBC encryption on input data"; }
    @Override public String[] paramNames() { return new String[]{"input"}; }
    @Override public void execute(String[] params) {
        byte[] input = params.length > 0 ? params[0].getBytes() : new byte[16];
        aesCbcEncryptionByteArray(input);
    }
});
toolkit.addTool(new McpTool() {
    @Override public String name() { return "aesCtr"; }
    @Override public String description() { return "Run AES-CTR decryption on input data"; }
    @Override public String[] paramNames() { return new String[]{"input"}; }
    @Override public void execute(String[] params) {
        byte[] input = params.length > 0 ? params[0].getBytes() : new byte[16];
        aesCtrDecryptionByteArray(input);
    }
});
toolkit.addTool(new McpTool() {
    @Override public String name() { return "pbkdf2"; }
    @Override public String description() { return "Run PBKDF2 key derivation"; }
    @Override public String[] paramNames() { return new String[]{"password", "iterations"}; }
    @Override public void execute(String[] params) {
        String password = params.length > 0 ? params[0] : "123456";
        int iterations = params.length > 1 ? Integer.parseInt(params[1]) : 100000;
        pbkdf2(password.getBytes(), iterations);
    }
});
toolkit.run(emulator.attach());

iOS Example — See IpaLoaderTest.java for an iOS IPA loading example with custom MCP tools:

IpaLoader ipaLoader = new IpaLoader64(ipa, new File("target/rootfs/ipa"));
LoadedIpa loader = ipaLoader.load(this);
emulator = loader.getEmulator();
loader.callEntry();
module = loader.getExecutable();

McpToolkit toolkit = new McpToolkit();
toolkit.addTool(new McpTool() {
    @Override public String name() { return "dumpClass"; }
    @Override public String description() { return "Dump an ObjC class definition by name"; }
    @Override public String[] paramNames() { return new String[]{"className"}; }
    @Override public void execute(String[] params) {
        String className = params.length > 0 ? params[0] : "AppDelegate";
        IClassDumper classDumper = ClassDumper.getInstance(emulator);
        System.out.println("dumpClass(" + className + "):\n" + classDumper.dumpClass(className));
    }
});
toolkit.addTool(new McpTool() {
    @Override public String name() { return "readVersion"; }
    @Override public String description() { return "Read the TelegramCoreVersionString from the executable"; }
    @Override public void execute(String[] params) {
        Symbol sym = module.findSymbolByName("_TelegramCoreVersionString");
        if (sym != null) {
            Pointer pointer = UnidbgPointer.pointer(emulator, sym.getAddress());
            if (pointer != null) {
                System.out.println("_TelegramCoreVersionString=" + pointer.getString(0));
            }
        }
    }
});
toolkit.run(emulator.attach());

Once the MCP server is started, AI can call these tools via MCP to run emulations with custom parameters, set breakpoints, trace execution, and inspect results — all without restarting the process.

Low-level API: You can also use Debugger.addMcpTool() + Debugger.run(DebugRunnable) directly for full control. McpToolkit is a higher-level wrapper that eliminates if-else dispatch.

Memory Leak Detection

Track guest-side memory allocations (mmap/munmap/brk) to detect leaks in emulated native code. Use try-with-resources — tracking starts on creation, and the leak report is printed automatically on close.

try (MemoryTracker tracker = emulator.traceMemoryLeaks()) {
    module.callFunction(emulator, "targetFunction", arg1, arg2);
}

Each leaked block includes guest ARM backtrace (module+offset+symbol) and host Java stack trace. Sample output:

=== Memory Leak Report ===
Tracking duration: 42ms
Total allocations: 5
Total deallocations: 3
Leaked blocks: 2
Total leaked size: 32768 bytes (32.0 KB)

--- Leak #1 ---
Address: 0x40001000, Size: 16384 (16.0 KB), Perms: rw-
Guest Backtrace:
  #0 0x40123456 libexample.so+0x3456 (malloc+0x12)
  #1 0x40124000 libexample.so+0x4000 (doSomething+0x48)
Host Stack Trace:
  com.github.unidbg.linux.AndroidElfLoader.mmap2(AndroidElfLoader.java:785)
  ...

You can also access the report programmatically before close:

try (MemoryTracker tracker = emulator.traceMemoryLeaks()) {
    module.callFunction(emulator, "targetFunction", arg1, arg2);
    List<AllocationRecord> leaks = tracker.getLeaks();
    assert leaks.isEmpty() : "Memory leak detected!";
}

Worker Pool

A thread-safe object pool for reusing emulator instances across multiple threads, avoiding the overhead of repeated initialization.

• Lazy initialization — Workers are created on-demand only when the pool is empty, not upfront.
• Max limit — Total alive workers (borrowed + idle) never exceeds the configured maximum.
• Idle cleanup — Workers idle for longer than the timeout (default 10 minutes) are automatically destroyed by the management thread.
• Min idle — A minimum number of workers (default 1) is always kept alive, even when idle.

1. Implement a Worker

public class MyWorker implements Worker {
    private final AndroidEmulator emulator;

    public MyWorker() {
        emulator = AndroidEmulatorBuilder.for64Bit().build();
        // load .so, call JNI_OnLoad, etc.
    }

    @Override
    public void destroy() {
        emulator.close();
    }

    public byte[] doWork(byte[] input) {
        // call native methods and return the result
    }
}

2. Create Pool, Borrow, and Close

// Create a worker pool (max = CPU cores, lazy-initialized)
WorkerPool pool = WorkerPoolFactory.create(MyWorker::new);
// Or specify max workers explicitly
// WorkerPool pool = WorkerPoolFactory.create(MyWorker::new, 4);

// Optional: customize idle timeout (default 10 minutes, minimum 1 minute)
pool.setIdleTimeout(30); // idle workers destroyed after 30 minutes
// Optional: customize minimum kept-alive workers (default 1, minimum 1)
pool.setMinIdle(2); // always keep at least 2 workers alive
// Optional: pre-create workers eagerly (default 0, fully lazy)
pool.setInitialSize(4); // eagerly create 4 workers on startup

// Concurrent invocation from multiple threads
ExecutorService executor = Executors.newFixedThreadPool(100);
for (int i = 0; i < 100; i++) {
    executor.submit(() -> {
        try (WorkerLoan<MyWorker> loan = pool.borrow(1, TimeUnit.MINUTES)) {
            if (loan != null) {
                byte[] result = loan.get().doWork(input);
            }
        } // worker is automatically returned to the pool
    });
}

executor.shutdown();
executor.awaitTermination(10, TimeUnit.MINUTES);
pool.close(); // destroy all workers and release resources

See TTEncryptWorker.java for a complete example.

Examples

Simple tests under src/test directory:

• TTEncrypt.java

---

• JniDispatch32.java


---

• JniDispatch64.java


---

• Utilities32.java


---

• Utilities64.java


More tests:

• QDReaderJni.java
• SignUtil.java

License

• unidbg uses software libraries from Apache Software Foundation.

Thanks

• unicorn
• dynarmic
• HookZz
• xHook
• AndroidNativeEmu
• usercorn
• keystone
• capstone
• idaemu
• jelf
• whale
• kaitai_struct
• fishhook
• runtime_class-dump
• mman-win32
